EN
1

DESCRIPTION

1.1

PURPOSE

The machine is intended for inflating air mattresses, toys,
sport ball, tires, floats.
1.2

OVERVIEW

Figure 1~7.
Carrying Handle
1
Connector Port
2
Deflating Port
3
Air Hose ( low
4
pressure)
Raft Nozzle
5
Air Hose ( high
6
pressure)
Ball Needle
7
Presta Valve Adaptor
8
Battery Release
9
Button
10 Power Cord
2

INSTALLATION

2.1

UNPACK THE MACHINE

Make sure that you correctly assemble the machine before
use.
• If parts of the machine are damaged, do not use the
machine.
• If parts are missing, do not operate the machine.
• If parts are damaged or missing, contact the service
center.
1. Open the package.
2. Read the documentation provided in the box.
3. Remove all the unassembled parts from the box.
4. Remove the machine from the box.
5. Discard the box and packing material in compliance with
local regulations.
For your personal safety, do not insert battery before the
tool is assembled completely.
2.2

INSTALL THE BATTERY PACK

Figure 2.
11 Quick connect valve
adaptor
12 ON/OFF Button
13 Mode Selection
Button
14 Digital Pressure
Display
15 Air Pressure Increase
Button
16 Air Pressure
Reduction Button
17 Start / Break Button
18 LED Light Button
WARNING
WARNING
WARNING
English
• If the battery pack or charger is damaged, replace the
battery pack or the charger.
• Stop the machine and wait until the motor stops before
you install or remove the battery pack.
• Read, know, and do the instructions in the battery and
charger manual.
1. Align the lift ribs on the battery pack with the grooves in
the battery compartment.
2. Push the battery pack into the battery compartment until
the battery pack locks into place.
3. When you hear a click, the battery pack is installed.
This machine can also connect to the 12V power outlet
directly. Insert the 12V power cord into the 12V power
outlet, this will automatically provide continuous 12V
current to your inflator.
Figure 3.
2.3

REMOVE THE BATTERY PACK

1. Push and hold the battery release button.
2. Remove the battery pack from the machine.
2.4

SELECT THE MODE

High Pressure mode
Figure 4.
Choose the high pressure mode to start the inflator when
you connect the air hose (high pressure) to the item.
1. Connect the quick connect valve adaptor to item you are
inflating.
2. Push down the valve lock lever to secure the connection.
Low Pressure Mode
Figure 5.
1. Insert low pressure air hose to the connector port and
rotate counterclockwise.
2. Use your desired nozzle to inflate the item.
Choose the low pressure mode to start the inflator when you
connect the air hose (low pressure) to the item.
Deflating Mode
1. To deflating item, insert low pressure air hose to the air
outlet.
2. Use your desired nozzle to deflate the item.
4
WARNING
TIP
NOTE
NOTE
