Overview and illustrations / Übersicht und Abbildungen
Standard
Nearfield
Multigas
Nadel/
Needle
Nearfield Nadel
/Nearfield Needle
* These values are only a course guideline. Depending on treated material, process parameters, following processes and process
requirements the actual results can vary significantly from the typical parameters in both directions. / Diese Werte dienen als
grobe Richtlinie. Je nach Ausgangsmaterial, Prozessparametern, Folgeprozess und Prozessanforderung können die
tatsächlichen Parameter in beide Richtungen deutlich von den angegebenen typischen Behandlungsparametern abweichen.
1
These operating instructions apply in addition to the operating instructions of the
piezobrush®PZ3. Follow all instructions of that document.
Caution – hot surface!
The exchange modules can become hot during operation. Do not touch them until they
have cooled down and take care not to damage thermally sensitive surfaces when
working with the exchange modules.
Do not reach into the work area during plasma generation. This can disturb the plasma
discharge and can also cause skin irritation or be perceived as painful.
Note!
Under certain circumstances, the electric fields generated by the device can damage
sensitive electronic components. Make sure that the components of your application are
not affected by the plasma process.
2
1000650100
2 - 10
1000650200
0,5 - 2
1000650300
2 - 20
1000650400
2 - 5
1000650500
0,5 - 2
2
~ 5 – 29
Air / Luft,
~ 5 – 50
N
2
~ 14
Air / Luft
~5 – 15
Ar, He,
N
2
~ 2 – 5
Air / Luft
~ 2 – 5
Air / Luft
3
4
x
x
x
x
Ar/He
x
x
5
BA_PZ3_ML piezobrush PZ3
Module / F0355300
1
2
5
6
3
4
6
