HOMCOM AA1-099 Bedienungsanleitung Seite 9

1
2
8
3
5
11
1.Handles
2.Rapid tightening lever for handles
3.Steering column spring button
4.Brake/mudguard
5.Locking lever for folding mechanism
6.Handle spring button
7.Handlebar stem
8.Rapid tightening lever for steering column
9.Steering column
10.Folding mechanism
11.Rapid tightening lever for folding mechanism
12.Plastic stopper
13.Handle locking mechanism
14.Brake handlebar
15.Brake mechanism
16.Brake lines
14
6
13
EN-3
12
9
16
7
10
4
15
