IX. Specification
Non-linearity within the 10 – 30 000 Hz band:
Weighted signal - noise interval:
Power supply voltage filtering capacitors:
The Reference amplifier meets all the requirements and standards binding within the EU
19
Sinusoidal power: 8 Ω / 2 x 140 W (CLASS AB) / 4 Ω / 2 x 260 W (CLASS AB)
Minimum impedance load: 1 Ω (temporary)
Power consumption: STATIC 40 VA – 1200 VA (PEAK)
Output impedance: –
Distortions – THD: 0.05% at 1 W / 8 Ω
Bandwidth: 5Hz – 100 Khz 3 dB / 1 W / 8Ω
10 – 30 000 Hz: ± 0.01 dB
Slew rate: 150 V/μs
Dynamics: –
130 dB (IHF – A)
Inputs 4 x universal – RCA XLR Amphenol, 1 x separated CD / DAC – RCA,
1 x phono MM – RCA, 1 x phono MC – RCA
Input sensitivity: 500 mV – universal inputs and separated CD / DAC, 500 mV – input XLR,
3 mV – input MM, 0,2 mV – input MC
Input impedance: 100 kΩ – RCA/DAC/CD, 22 kΩ – XLR, 47 kΩ – RCA MM, 100 Ω – RCA MC
Volume potentiometer: controlled by means of a "Blue Velvet" step motor manufactured by the Alps company
Grid transformers: 2 x toroid, each with power of 500 VA
4 x 12 000 μF – Nippon Chemi–Con
Remote control: RC5 code (volume)
Net weight: 16 kg
Dimensions : 430 x 95 x 358 mm
Manufacturer's warranty: 24 months
| 0.02% at 120 W / 8 Ω
