TECHNICAL DATA

As specified on the model plate - Constructed in compliance with regulations and directives in force.
ELECTRICAL CONNECTION
Check that power supply voltage is the same as electric system. Check the plug is suitable for the workplace. Use the
lamp in the areas specified and regulated by current workplace and electric system standards.
The lamp is supplied with already pre-charged batteries, however, it is recommended to charge the lamp fully
for at least 4 hours before using it.
N.B.: the battery will reach full capacity after at least 5 complete cycles of use. Until then the autonomy of the lamp
may seem lower than declared.
During the charging phase both the lamp (1) and the power supply (2) may heat up slightly.
CHARGING WITH 100-240V 2A POWER SUPPLY (2) AND CHARGING CABLE (3)
Insert the power supply unit (2) into a suitable socket, insert the USB plug (3a) of the charging cable (3) into the pow-
er supply unit (2), insert the USB plug C (3b) into the lamp (1a).
Check that the charge indicator (1b) on the lamp handle lights up.
The charge indicator has 3 green LEDs and 1 red LED. The indications are as follows:
one of the 4 LEDs is flashing: the lamp is being recharged.
all four fixed LEDs: the lamp is charged
only the red led is lit: the lamp is in power reserve or empty
The battery charge indicator (1b) is only activated when the lamp is charging or for 7 seconds when it is switched on
and after it has switched off.
CHARGING WITH POWER SUPPLY (2) AND INDUCTION CHARGING BASE (4)
Plug the power supply unit (2) into a suitable socket, insert the USB plug (4a) of the induction charging base (4) into
the power supply unit (2).
Place the lamp (1) on the charging base (4) so that the magnets (4b) on the charging base and the magnets (1f) on
the lamp attract each other, allowing the lamp to be positioned correctly.
On the recharging base there is an indicator light (4c) which takes on the following colour
blue: the charging base is powered
red: the lamp is correctly positioned
When the lamp (1) is on the charging base (4) the LEDs on the handle (1b) indicate the battery charge status.
To turn the lamp on, disconnect the USB C plug (3b) and press the button (1c) on the handle.
To decrease the luminous intensity of the led (1d) press and keep the button (1c) pressed again.
The next time the LED (1d) lights up, it will return to its maximum luminous intensity.
The first quick press of the button (1c) turns on the main led (1d) and the second quick press of the button (1c) turns
off the main led (1d) and turns on the front led (1e).
It is not possible to turn on the lamp if it is being recharged.
Even if the leds (1d and 1e) are class 1 and therefore do not present any risk for people (photobiological safety), avoid
pointing the light beam directly into the eyes.
To switch off the lamp (1) press the button (1c) again.
On the lamp (1) there are 2 magnets (6 and 7). Make sure that the surface to which you want to attach the lamp is
clean and has a sufficiently flat and large area for the magnets to adhere correctly.
The lamp is equipped with a swivel hook (5). In case of use, check that the hooking area is sufficiently solid.
The hook should only be used to suspend the lamp (1).
Always make sure that the lamp does not have any faults that could affect its safety.
Do not open the lamp or any of its components.
The light source contained in this appliance may only be replaced by the manufacturer or his service department.
Keep your lamp clean.
Only use accessories and spares authorised by the manufacturer.
12 months from date of purchase
The warranty covers free repair or replacement in our facility of parts which, according to our binding decision, exhibit operating de-
fects. The warranty does not cover any form of compensation whatsoever. The warranty does not cover the parts subjected to wear
(batteries, transparent cap etc.)
The shipping costs must be borne by the purchaser.

SAFETY INSTRUCTIONS

INSTRUCTIONS FOR USE

GENERAL PRECAUTIONS

WARRANTY
