CIRCUS DIVISION TP700 Technische Bedienungsanleitung Seite 7

VERSATILITY
TEXT LEGEND
- (H) = Height
- (A) = Distance between legs
- (D1) = Distance between legs at 3,50 m
- (D2) = Distance between legs at 2,80 m
- (D3) = Distance between legs at 1,50 m
(1) MAXIMUM CONFIGURATION - 5 sections per leg
D1 = 2,80 m
A = 5,40 m
(2) MIDWAY CONFIGURATION - 4 sections per leg
D2 = 2,25 m
A = 4,40 m
(3) MINIMUM CONFIGURATION - 3 sections per leg
D3 = 2,25 m
A = 3,40 m
USER MANUAL
H = 7,00 m
H = 5,60 m
H = 4,20 m
SIMPLE TRANSPORTATION
- 1 box 60 x 40 x 40 cm - 25 kg
- pole lenght - 175 cm
64 cm
