4. Characteristics

4.1 Electrical characteristics:

• Dedicated external power supply from a wall-mount
switching power supply module with the following tech-
nical specifics:
1. AC Input: 100-240 Vac - 50 / 60Hz - 1A.
2. DC Output: 24Vdc / 1.5A.
• Power button
• Feed button
1. Manual/automatic mode change by pressing
and holding it.
2. Roll feed in manual mode.
• Optical sensor for label detection up to 1.97".

4.2 Mechanical characteristics:

• Weight: 4 kg (8.8 lbs).
• Dimensions: 340 x 315 x 300 mm (13.4"x 12.4" x 11.8")
[L x W x H].
• Speed: 0.1 m/s (0.33 foot per second).
• Maximum roll diameter: 135mm (5.3").
• Maximum roll weight: 2 kg (4.4 lbs).
• Core diameter: 50.8mm - 76.2mm (2"- 3").
• Maximum label width: 140mm (5.5").
• Maximum sensor rotation angle: 105°.
❷
with integrated LED light.
❸
with double function:
