SETTING-UP THE RC30
This section shows you how to setup and run the thermostat in 3 simple steps:
STEP 1: Installing the Batteries
Note: if the 'Low Battery' Indicator
or digits are displayed) replace the batteries as follows, otherwise, please go directly to Step 2:
Setting the Date and Time.
To install the Batteries:
a. Lift up the front cover of the thermostat to reveal the battery cover and product controls.
b. Remove the battery cover by pressing down and sliding out.
c. Insert the 2 x AA LR6 Alkaline Batteries supplied with the thermostat, ensuring the correct
orientation (see 'Controls Layout' on page 12).
d. After a short pause the thermostat will display information on the screen and is now ready for
use.
e. Replace the battery cover by sliding it firmly back into the front of the thermostat.
STEP 2: Setting the Day and Time
To set the Day and Time:
a. Press the DAY button once and the 'day indicator' will begin to flash.
b. Press the DAY button until the correct day is reached (Day 1 = Monday). Press the green
button to confirm.
d. Press either of the
the time digits (when the unit is powered for the first time the display shows 12:00).
e. Use the or
Each press of the buttons will change the time by one minute and holding them down will
change the time slowly at first and get progressively quicker.
Note: If this mode is entered accidentally then press the AUTO, MAN or OFF buttons to exit.
STEP 3: Running the Built-in Heating Program
The thermostat is now ready for operation. Press the AUTO button and the built-in heating program
will start running. Note: The built-in heating program has been designed to provide normal comfort
requirements, but if you want to customise the settings please see the next section 'Programming
the RC30'.
PROGRAMMING THE RC30
The Built-in Heating Program
The built-in heating program has 4 temperature level changes per day that can be set between
3.00am and 2.50am the following day - allowing you to maintain the evening temperature after
midnight. Each temperature level can be set between 5°C and 35°C, and adjusted in 0.5°C
increments. The factory default program for heating is as follows.
Monday to Friday (Day
1 to 5)
Saturday & Sunday
(Day 6 & 7)
is showing or the thermostat screen is blank (no symbols
or buttons once to enter time setting mode. The LCD screen flashes
buttons to set the correct time then press the green
Period
Time
Temperature
Period
Time
Temperature
1 2 3
6:30 8:00 18:00
21°C 18°C 21°C
1 2 3
8:00 10:00 18:00
21°C 21°C 21°C
EN
button to confirm.
4
22:30
16°C
4
23:00
26°C
