Description
The ACV RC30 is a programmable
room thermostat designed
control your heating
efficiently, providing comfortable
temperatures when you are at
home and energy savings when
you are away. The
instructions explain how to set
up, program and operate your
ACV RC30 Programmable Room
Thermostat.

Controls Layout

17
16
DAY
COPY
DAY
15
14
13
12
1
LCD Screen
2
Battery Low Indicator
3
Time Display
4
Heating Required Indicator
5
Day Indicator
6
Temperature Display
12
Features
• Ergonomic user interface featuring an 'OK-button'.
to
• Large LCD (Liquid Crystal Display) Screen.
system
• 7-day heating program to match your lifestyle, whilst
maximising energy savings.
• 6 independent temperature levels per day (from 5°C to
following
35°C).
• Holiday button saves energy by letting you reduce the
temperature for 1 to 99 days.
• Built-in Memory holds the user program indefinitely.
1 2 3
1 2 3
PROGRAM
7
Temperature Change Buttons
8
Temperature Enquiry Button
9
Operating Mode Buttons
10
Green OK Button
11
Battery Compartment
12
Battery Cover
4 5
4 5 6 7
OFFMANAUTO
1..4
RC30 - USER GUIDE
6
7
8
AUTO
MAN
9
OFF
10
11
13
Holiday Function Button
14
Program Buttons
15
Copy Day Button
16
Day Select Button
17
Time Change Buttons
