3. SPECIFICATIONS

Item
Light Source type
Color temperature
LED life
Light guide adapter
Brightness control
Input voltage
Consumption Power
Regulatory Approvals
Equipment Class
Mode of Operation
Water Resistant
Operating Environment
Temperature
Relative Humidity
Air Pressure
Storage Environment
Temperature
Relative Humidity
Air Pressure
Dimensions
Weight
LIT-168 TeDan Surgical - ML-0051
Rev. G
Specification
LED (Light Emitting Diode)
6500 K
50,000 hours (typical)
TSI
PWM (Pulse-width Modulation) – 0-100% Dimming
100-240V AC, 50/60 Hz
52 watt (nominal)
CAN/CSA-C22.2 No.60601-1-08, TC 2:2011 (Corrigendum 2),
CAN/CSA-C22.2 No. 60601-2-18:11(IEC 60601 4
CE Mark
BF-type, Conforms to CISPR 11 Class A
Continuous operation
Not Protected Equipment, IPX0
+0° to +40° C (32° to 104° F)
30 to 85%rh, non condensing
700 to 1060 hPa
-20° to +60° C (-4° to 140° F)
0 to 95%rh, non condensing
700 to 1060 hPa
4.65" W x 3.32" H x 7.25" D
2.5 lbs./1.14 kg
