softener and open faucets at the top
and at the bottom of your house to
drain your installation.
The connection to the softener must
be done using flexible hoses.
The connection to the drain should be
done in accordance with legislation.
Often an airgap is needed.
In order to adequately compensate
the tank elongation the flexible
tubes must be installed horizontally.
If the flexible piping connection is
installed in vertical position, instead
of compensating the elongation, it
will create additional stresses on the
valve & tank assembly.
The flexible piping connection must
also be installed stretched, avoiding
excessive length. For instance 20 –
40 cm is sufficient. Excessively long
and non-stretched flexible piping
connection will create stresses
on the valve and tank assembly
when the system is pressurized, as
illustrated in the below picture: on the
left the assembly when the system
is unpressurised, on the right the
flexible piping connection when put
under pressure tends to lift up the
valve when stretching up.
Filter
A pre-filter is needed upstream of the
softener in order to protect the valve
from impurities present in the water
that might cause damage to the valve
or its seals.
Water temperature
The temperature of water should not
exceed 35 °C and the installation
should not be subjected to freezing
conditions (risk of very serious
damage).
Do not use the softener on hot water!
Salt
Only use salt tablets for water
softening applications (purity should
be at least 99.5%). Other types of salt,
for example, finely granulated are not
permitted.
