14

ASSEMBLY

14.1 Preparing Activities

14.1.1 Checking the Delivery Content

Check the machine immediately after delivery for transport damage and missing parts. Report
any damage or missing parts immediately to your dealer or the forwarder. Visible transport
damage must also be noted immediately on the delivery note in accordance with the warranty
provisions, otherwise the goods will be deemed to have been properly accepted.

14.1.2 The workplace

Choose a suitable place for the machine. Pay attention to the safety requirements and the
dimensions of the machine. The selected location must ensure a suitable connection to the
electrical supply.
14.2 Electriclal connection (NEU)
Dangerous electrical voltage! The machine may only be connected to the mains
supply and the associated checks carried out by a qualified electrician or under the
instruction and supervision of a qualified electrician!
1. Check that the neutral connection and protective earthing are functioning properly
2. Check that the supply voltage and frequency correspond to the specifications of the
machine
A deviation from the value of the supply voltage of ± 5% is permissible.
A short-circuit fuse must be provided in the power supply system of the machine!
3. Find the required cross-section of the supply cable (it is recommended to use a cable type
H07RN (WDE0282), taking measures to protect against mechanical damage) in a current
capacity data sheet.
4. Make sure that the power source is protected by a residual current circuit breaker.
5. Connect the unit only to a properly grounded outlet.
6. When using an extension cable, make sure that it is dimensioned appropriately for the
connected load of the machine (the connected load can be found in the technical data).
You can find the correlation between cable cross-section and cable length in specialist
literature or consult an electrician.
14.3 Assembly
The machine has been disassembled for transport and must be assembled before use. Follow the
instructions below:
HOLZMANN MASCHINEN GmbH
W A R N I N G
N O I T I C E
Deviation of the supply voltage and frequency
