10 Fingernail polish or false ngernails.
11 Weak pulse quality (low perfusion).
12 Low hemoglobin.
Carefully read these instructions before using the device. Not following these
instructions may cause incorrect measurements or damage to the device or
the user.
The manufacturer is not responsible for the safety, reliability and proper
functioning of the device nor for monitoring errors or damage to persons and
the product if the user fails to read these instructions, and such events are not
covered by the warranty.

TECHNICAL SPECIFICATIONS

Display type: LED
SpO2: Measuring interval: 0-100%
Accuracy: 70%-100%, ±2%; ≤69% no de nition
Resolution: 1%
31
Pulse frequency:
Measuring interval: 30-250 BPM
Accuracy: 30~99bpm, ±2bpm; 100~250bpm, ±2%
Resolution: 1bpm
Pulse intensity: Bar graph indicator
Power supply requirements:
Two AAA alkaline batteries 1.5V - Lifetime until 30 hours
Energy consumption: Less than 40mA
Battery charge indication:
Dimensions:
Length: 57mm〜59mm
Width: 33mm〜35mm
Height: 34mm〜36mm
Weight:
40g〜60g (including two AAA batteries)
Ambient requirements:
Operating temperature: 5〜40℃
Storage temperature: -25〜70℃
Ambient humidity: 15〜93%, without formation of
condensate during operation.
≤93%, without formation of condensate during storage.
Atmospheric pressure: 70kPa〜106kPa
