LAN eBus Konfiguration
Example:
Input: arp -s 10.66.22.98
00-20-4a-86-c9-91
Input: telnet 10.66.22.98 1
Response:
Establishing connection with
10.66.22.98... Connection to host
could not be established; port 1:
connection could not be establis-
hed
Input: telnet 10.66.22.98 9999
Input: Enter (within 2 seconds)
Response:
MAC address 00204AA6C991
Software version V6.5.0.7
(070919) XPTEXE
Press Enter for Setup Mode
basic parameters
Hardware: Ethernet TPI
IP addr 10.66.22.98,
no gateway set,
netmask 255.255.255.0
Security
SNMP is
SNMP Community Name:
Setup is
TFTP Download is enabled
Port 77FEh is
Web Server is
Web Setup is
ECHO is
Enhanced password is
Port 77F0h is
Channel 1
Baudrate 38400, I/F Mode 7F, Flow
00 Port 08000
Connect Mode: C0
Send ‚+++' in Modem Mode enabled
Show IP addr after ‚RING' enabled
Auto increment source port disa-
bled
Remote IP Adr: --- none ---,
Port 00000
Disconn Mode: 00
Flush
Pack Cntrl:
18
enabled
public Telnet
enabled
enabled
enabled
enabled
disabled
disabled
enabled
Mode: 80
20
Expert
TCP Keepalive:
CPU performance: Regular
Monitor Mode @ bootup: enabled
RS-485 tx enable:
HTTP Port Number:
SMTP Port Number:
MTU Size:
Alternate MAC:
Ethernet connection type:
auto-negotiate
*** E-mail
Mail server: 0.0.0.0
Unit:
Domain:
Recipient 1:
Recipient 2:
Trigger 1
Serial trigger input: disabled
Channel: 1
Match: 00,00
Trigger input1: X
Trigger input2: X
Trigger input3: X
Message :
Priority: L
Min. notification interval: 1 s
Re-notification interval : 0 s
Trigger 2
Serial trigger input: disabled
Channel: 1
Match: 00,00
Trigger input1: X
Trigger input2: X
Trigger input3: X
Message:
Priority: L
Min. notification interval: 1 s
Re-notification interval: 0 s
Trigger 3
Serial trigger input: disabled
Channel: 1
Match: 00,00
Trigger input1: X
Trigger input2: X
Trigger input3: X
Message:
Priority: L
Min. notification interval: 1 s
Re-notification interval : 0 s
45s
active low
80
25
1400
disabled
