MFR-IG/-EA/-DO
MFR-EA Ausführung Edelstahl
(Bestellbeispiel: MFR-EAR15E)
Gewinde
Bestell-Nr.
[RP]
Einfachsieb
½
MFR-EAR15E
¾
MFR-EAR20E
1
MFR-EAR25E
1 ¼
MFR-EAR32E
1 ½
MFR-EAR40E
2
MFR-EAR50E
MFR-D0 Ausführung Edelstahl
(Bestellbeispiel: MFR-DOR15)
Bestell-Nr.
MFR-DOR08
DN08
MFR-DOR10
DN10
MFR-DOR15
DN15
MFR-DOR25
DN25
MFR-DOR40
DN40
MFR-DOR50
DN50
MFR-DOR80
DN80
11. Abmessungen
MFR-IG
Seite 10
Bestell-Nr.
Doppelsieb
[mm]
MFR-EAR15D
MFR-EAR20D
MFR-EAR25D
MFR-EAR32D
MFR-EAR40D
MFR-EAR50D
Größe
L
[mm]
¼"
65,0
⅜"
65,0
½"
65,0
1"
90,0
1½"
120,0
2"
140,0
3"
200,0
M
H
L
[mm]
[mm]
12,5
42,5
65,0
15,5
49,0
75,0
18,5
57,5
90,0
23,0
65,0
110,0
26,5
74,0
120,0
33,5
85,0
150,0
H
D
[mm]
[mm]
51,0
10,0
51,0
12,0
51,0
15,0
72,0
25,0
87,0
40,0
103,0
50,0
143,0
80,0
