Spezifikationen
QTT=8}"
linesensor {line_num} events type show
linesensor {line_num} maxval set {float}
linesensor {line_num} maxval show
linesensor {line_num} minval set {float}
linesensor {line_num} minval show
linesensor {line_num} hyst set {float}
linesensor {line_num} hyst show
linesensor {line_num} {BELOWMIN=0|
ABOVEMIN=1|ABOVEMAX=2|BELOWMAX=3}
port set {port_num}
linesensor {line_num} {BELOWMIN=0|
ABOVEMIN=1|ABOVEMAX=2|BELOWMAX=3}
port show
linesensor {line_num} {BELOWMIN=0|
ABOVEMIN=1|ABOVEMAX=2|BELOWMAX=3}
state set {OFF=0|ON=1|DISABLED=2}
linesensor {line_num} {BELOWMIN=0|
ABOVEMIN=1|ABOVEMAX=2|BELOWMAX=3}
state show
modbus
modbus enabled set <off=0/on=1>
modbus enabled show
modbus port set <ip_port>
modbus port show
mqtt
mqtt {broker_idx} enabled set {OFF=0|ON=1}
mqtt {broker_idx} enabled show
mqtt {broker_idx} server set "{dns_name}"
mqtt {broker_idx} server show
mqtt {broker_idx} tls enabled set {OFF=0|ON=1}
mqtt {broker_idx} tls enabled show
mqtt {broker_idx} port set {ip_port}
mqtt {broker_idx} port show
mqtt {broker_idx} user set "{username}"
mqtt {broker_idx} user show
mqtt {broker_idx} passwd set "{passwd}"
mqtt {broker_idx} passwd hash set "{passwd}"
mqtt {broker_idx} client set "{name}"
mqtt {broker_idx} client show
mqtt {broker_idx} qos set {QOS0=0|QOS1=1}
mqtt {broker_idx} qos show
mqtt {broker_idx} keepalive set {num_secs}
mqtt {broker_idx} keepalive show
mqtt {broker_idx} topic set "{name}"
mqtt {broker_idx} topic show
mqtt {broker_idx} console enabled set {OFF=0|
ON=1}
mqtt {broker_idx} console enabled show
mqtt {broker_idx} device data timer set
{num_secs}
mqtt {broker_idx} device data timer show
port
port {port_num} state set {OFF=0|ON=1}
port {port_num} state show
port all state set "{port_list}" {OFF=0|ON=1}
port all state {MODE0=0|MODE1=1|MODE2=2}
show
port all set {OFF=0|ON=1|OFF_REV=2|
ON_REV=3}
port restart all set {REINIT=0|
OFF_REV_REINIT=1,OFF_REINIT=2}
port {port_num} reset
port {port_num} toggle
port {port_num} batch set {OFF=0|ON=1} wait
{num_secs} {OFF=0|ON=1}
port {port_num} batch cancel
port {port_num} label set "{name}"
port {port_num} label show
port {port_num} initstate coldstart set {OFF=0|
ON=1|REMEMBER=2}
port {port_num} initstate coldstart show
port {port_num} initstate delay set {num}
89
Expert Power Control 1202/1292
LEGACY - shows what event types are enabled
LEGACY - sets maximum value for line meter
LEGACY - shows maximum value for line meter
LEGACY - sets minimum value for line meter
LEGACY - shows minimum value for line meter
LEGACY - sets hysterese value for line meter
LEGACY - shows hysterese value for line meter
LEGACY - sets Port for Power Port Switching
actions
LEGACY - shows Port for Power Port Switching
actions
LEGACY - sets Port state for Power Port
Switching actions
LEGACY - shows Port state for Power Port
Switching actions
enters cmd group "modbus"
enables Modbus TCP support
shows if Modbus is enabled
sets Modbus TCP port
shows Modbus TCP port
enters cmd group "mqtt"
enable mqtt
shows if mqtt enabled
sets broker name
shows broker name
enable TLS
shows if TLS enabled
set broker TCP/IP port
shows broker TCP/IP port
sets username
shows username
sets password
sets hashed passwd
sets client name
shows client name
sets QoS level
shows QoS level
sets keep-alive time
shows keep-alive time
sets topic prefix
shwos topic prefix
permit console cmds
shows if console cmds allowed
sets telemetry interval
shows telemetry interval
enters cmd group "port"
sets port to new state
shows port state
sets several ports in one cmd - e.g. port all state
set "1,3,5" 1
shows all port states in 3 different view modes
switch all ports on/off forward or reverse
reinit coldstart sequence (optional first all off)
start reset sequence for port
toggles port
starts batch mode for port
cancels batch mode
sets port label name
shows port label name
sets port coldstart initialization
shows port coldstart initialization
sets port init delay
L
L
L
L
L
L
L
L
L
L
L
4
