GUDE Systems Expert Power Control 1202 Anleitung Seite 76

Spezifikationen
epc1202AbsEnergyActive
epc1202PowerActive
epc1202Current
epc1202Voltage
epc1202Frequency
epc1202PowerFactor
epc1202Pangle
epc1202PowerApparent
epc1202PowerReactive
epc1202AbsEnergyReactive
epc1202AbsEnergyActiveResettab
le
epc1202AbsEnergyReactiveResett
able
epc1202ResetTime
epc1202ForwEnergyActive
epc1202ForwEnergyReactive
epc1202ForwEnergyActiveResetta
ble
epc1202ForwEnergyReactiveRese
ttable
epc1202RevEnergyActive
epc1202RevEnergyReactive
epc1202RevEnergyActiveResettab
le
epc1202RevEnergyReactiveResett
able
epc1202LineSensorName
epc1202OVPIndex
epc1202OVPStatus
epc1202NTPTimeValid
epc1202NTPUnixTime
epc1202NTPLastValidTimestamp
epc1202SensorIndex
epc1202TempSensor
epc1202HygroSensor
epc1202InputSensor
epc1202AirPressure
epc1202DewPoint
epc1202DewPointDiff
Expert Power Control 1202/1292
0 = data not active, 1 = data valid
.43.1.5.1.2.1.3.x
Absolute Active Energy counter.
.43.1.5.1.2.1.4.x
Active Power
.43.1.5.1.2.1.5.x
Actual Curent on Power Channel.
.43.1.5.1.2.1.6.x
Actual Voltage on Power Channel
.43.1.5.1.2.1.7.x
Frequency of Power Channel
.43.1.5.1.2.1.8.x
Power Factor of Channel between -1.0 and 1.00
.43.1.5.1.2.1.9.x
Phase Angle between Voltage and L Line Current between -180.0 and
180.0
.43.1.5.1.2.1.10.x
L Line Mean Apparent Power
.43.1.5.1.2.1.11.x
L Line Mean Reactive Power
.43.1.5.1.2.1.12.x
Absolute Reactive Energy counter.
.43.1.5.1.2.1.13.x
Resettable Absolute Active Energy counter. Writing '0' resets all
resettable counter.
.43.1.5.1.2.1.14.x
Resettable Absolute Reactive Energy counter.
.43.1.5.1.2.1.15.x
Time in seconds since last Energy Counter reset.
.43.1.5.1.2.1.16.x
Forward Active Energy counter.
.43.1.5.1.2.1.17.x
Forward Reactive Energy counter.
.43.1.5.1.2.1.18.x
Resettable Forward Active Energy counter.
.43.1.5.1.2.1.19.x
Resettable Forward Reactive Energy counter.
.43.1.5.1.2.1.20.x
Reverse Active Energy counter.
.43.1.5.1.2.1.21.x
Reverse Reactive Energy counter.
.43.1.5.1.2.1.22.x
Resettable Reverse Active Energy counter.
.43.1.5.1.2.1.23.x
Resettable Reverse Reactive Energy counter.
.43.1.5.1.2.1.100.x
A textual string containing name of a Line Sensor
.43.1.5.2.1.1.x
None
.43.1.5.2.1.2.x
shows the status of the built-in Overvoltage Protection
.43.1.5.15.1.0
Show if valid Time is received
.43.1.5.15.2.0
show received NTP time as unixtime (secs since 1 January 1970)
.43.1.5.15.3.0
show seconds since last valid NTP timestamp received
.43.1.6.1.1.1.x
None
.43.1.6.1.1.2.x
actual temperature
.43.1.6.1.1.3.x
actual humidity
.43.1.6.1.1.4.x
logical state of input sensor
.43.1.6.1.1.5.x
actual air pressure
.43.1.6.1.1.6.x
dew point for actual temperature and humidity
.43.1.6.1.1.7.x
difference between dew point and actual temperature (Temp -
Gauge32 RO
Integer32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Gauge32 RO
Gauge32 RW
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
OCTETS RW
Integer32 RO
INTEGER RO
INTEGER RO
Unsigned32 RO
Unsigned32 RO
Integer32 RO
Integer32 RO
Integer32 RO
INTEGER RO
Integer32 RO
Integer32 RO
Integer32 RO
