Important
Transmitter and receiver must be in the same group! (1-4)
8. KNX-Adaption
In order to be able to control Ape Labs lights via KNX, the CONNECT must
be set as a wireless DMX transmitter. The CONNECT receives the DMX 512
input signal via the Ape Labs KNX-DMX adapter ( item no. 100078 ). The
KNX - Adaption only works in connection with the Ape Labs KNX DMX ad-
apter.
Danger! A KNX bus installation should be performed by an electrician.
General installation instructions
• Standard DMX mode for KNX operation: 4C mode (RGBW)
• Address your Ape Labs lamps with individual DMX addresses (Follow
the APP instructions)
• Follow the QR codes on the KNX-DMX adapter

9. Features of the app

Due to the continuous further development of the app, we cannot go into
the individual functions of the app in these operating instructions. The
lamp-related functions are described in the general Ape Labs user guide.
This manual can be found here:

10. Service mode settings

1. Press the fixture button and hold it for about 5 seconds. The device will
turn on and blink blue/white. The button can now be released. (Lamps
18
without a button on the housing have a service button on the electro-
nics board. E.g. ApeCoin )
2. As soon as all settings have been made, a short push of a button is
enough to exit the service mode.
Possible service mode settings
• Light pairing
• Battery level indicator
• Flicker free mode
• Reset light settings
