Vor dem ersten Gebrauch Lesen Sie vor dem ersten Gebrauch die Bedienungsanleitung und die Sicherheitshinweise aufmerksam durch . Bewahren Sie die Bedie- nungsanleitung zusammen mit dem Gerät für den späteren Gebrauch auf. Sollten andere Personen dieses Gerät nutzen, so stellen Sie ihnen diese Anleitung zur Verfügung.
Beleuchtungsstärkemessung Die Messung von ungebündeltem Licht wird standardmäßig ohne Reflektoren durchgeführt. Der lineare Abstand von der LED-Licht- quelle zum Beleuchtungsstärkemesser beträgt 1 Meter. Wenn der Einstrahlungswinkel des Reflektors kleiner und dessen Tiefe tiefer wird, dann wird das Licht gebündelt. Das Zentrum des Lichts ist sehr hell, der umgebende Schein erscheint gedämpft. Der Lichtver hältnis-Kontrast wird damit größer und das Licht am ent- sprechenden Mittelpunkt der Messung wird gedämpft.
Drücken und halten Sie den Ein-/Ausschalter [13], um das Gerät einzuschalten. Das Strom-Symbol [17] wird im LC- Display angezeigt. 2 . Optionaler Akku-Betrieb: Das EF-150Bi kann optional über den Jinbei EF-VM V- Mount-Akku-Adapter betrie- ben werden. Stecken Sie dazu ein Ende des Kabels in den V-Mount-Akku-Adapter-An-...
Seite 9
Beschreibung der Funktion Einstellung der Helligkeit Drehen Sie den Funktionsknopf [12], um die Helligkeit einzustellen. Der Helligkeitsbereich lässt sich zwischen 1 % und 100 % einstellen, „--“ bedeutet, dass das LED-Dauerlicht ausgeschaltet ist. Einstellung der Farbtemperatur Drücken Sie kurz den Funktionsknopf [12]. Das Symbol „K“ blinkt nun im Display.
Seite 10
Beschreibung der Funktion Voreingestellte Lichteffekte Drehen Sie den Lichteffekt-Drehknopf [7], um in den Modus für vor- eingestellte Lichteffekte zu gelangen. Die Lichteffekte laufen kontinuierlich weiter. Drücken Sie den Lichteffekt-Pause- / Lichteffekt-Wiedergabe-Knopf | Lüfter-Schalter [8], um den ausgewählten Effekt zu pausieren oder neu zu starten. Um das das Lichteffekt-Menü zu verlassen, drehen Sie am Lichteffekt-Drehknopf [7].
Seite 11
Drahtlose 2,4-GHz-Fernbedienung Drücken Sie kurz den WiFi-Einstellungs-Knopf [11], das WiFi-Symbol [15] blinkt. Durch Drehen des Funktionsknopfs [12] können Sie nun die WiFi-Verbindung des EF-150Bi aktivieren oder deaktivieren. Drücken Sie den WiFi-Einstellungs-Knopf [11] und stellen Sie mit dem Funktionsknopf [12] die Gruppe (GR) und den Kanal (CH) nacheinan- der ein.
„Jinbei”-App / Bluetooth®* Laden Sie die „Jinbei“-App für iOS aus dem App Store oder die „Stu- dio“ App aus dem Amazon App Store für Android herunter (iOS 9.0 oder höher, Android 5.0 oder höher). Verbindung mit dem Smartphone 1. Aktivieren Sie Bluetooth®* an Ihrem Smartphone.
Seite 13
„Jinbei”-App / Bluetooth®* Erhältlich im Hinweis: Soll ein anderes Smartphone als bisher zur Nutzung des LED-Dauerlichts verwendet werden, so muss zunächst die Ver- bindung zum vorigen Smartphone unterbrochen werden und das LED-Dauerlicht aus den Einstellungen in der App auf dem vorherigen Smartphone gelöscht werden.
Technische Daten EF-150Bi Anzahl LEDs Leistung 170 W Energieeffizienzklasse (EU 2017/1369) EU-Energieeffizienzklassen-Spektrum A – G (EU 2017/1369) Farbtemperatur 2.700 – 6.500 K Color rendering index (CRI) | Television 97 | 98 Lighting Consistency Index (TLCI) Leistungseinstellung in % 0 – 100% in 1 %-Schritten Beleuchtungsstärke (Lux-Messungen 18.200 / 4.660 / 2.140 lx...
Seite 15
Aluminium Material Lichtkopf Aluminium, Plastik Maße | Gewicht 26,5 x 13,5 x 23 cm | 2,2 kg Lieferumfang EF-150Bi, EF-Boost-Ref- lektor 70°, Schutzkappe, Netzkabel (4,5 m), Be- dienungsanleitung Wir behalten uns das Recht vor, Funktionen oder Parameter ohne weitere Ankündigung zu aktualisieren. Druckfehler und Irrtümer vorbehalten. Das Reproduzieren dieser Bedienungs- anleitung –...
Sicherheitshinweise Gefahr durch elektrischen Strom! Fehlerhafte elektrische Installationen oder eine übermäßige Netz- spannung können Stromschlag verursachen. – Schließen Sie das Produkt nur dann an, wenn die Netzspannung der Steckdose mit den Angaben auf dem Typenschild überein- stimmt. – Das Produkt an eine leicht zugängliche Steckdose anschließen, damit Sie es bei Problemen schnell vom Netz trennen können.
Seite 17
Sicherheitshinweise Achtung! – Niemals das Netzkabel als Tragegriff benutzen. – Produkt und Zubehör von offenen Flammen, heißen Oberflächen und leicht entflammbaren Materialien fernhalten. – Verlegen Sie das Netzkabel so, dass es keine Stolpergefahr dar- stellt. – Knicken Sie das Netzkabel nicht und legen Sie es nicht über schar- fe Kanten. Achtung! Gefahr für Kinder und Personen mit eingeschränkten physischen, sensorischen oder geistigen Fähigkeiten (z .
Seite 18
Sicherheitshinweise – Filmen Sie weder Auto-, Bus-, Fahrrad-, Motorradfahrer noch Zug- führer während der Fahrt mit diesem Produkt. Der Fahrer kann ge- blendet werden und so einen Unfall verursachen. Dieses gilt auch für nicht aufgeführte Personen oder Gruppen, wenn durch eine mögliche Blendung ein Unfall verursacht werden könnte.
Geräte, die mit diesem Symbol gekennzeichnet sind, dürfen nicht mit dem Hausmüll entsorgt werden! Sie sind gesetzlich dazu verpflichtet, Altgeräte getrennt vom Hausmüll zu entsor- gen. Informationen zu Sammelstellen, die Altgeräte kostenlos entge- gennehmen, erhalten Sie bei Ihrer Gemeinde- oder Stadtverwaltung. Konformität Hiermit erklärt die RCP Handels-GmbH & Co. KG, dass dieser Funkanlagentyp „Jinbei EF-150Bi LED-Dauerlicht” der Richtlinie 2014/53/EU entspricht. Der vollständige Text der EU-Konformitäts- erklärung ist unter folgender Internetadresse https://www.jinbei-deutschland.de/egk/ef150bi RCP Handels-GmbH & Co. KG In de Tarpen 42, 22848 Norderstedt Deutschland...
Before the First Use Read the operating instructions and the safety instructions carefully before using the device for the first time. Keep the operating instructions together with the device for future use. If other people use this device, make this manual available to them. If you pass on the device to a third party, this manual belongs to the device and must be supplied with it. Intended Use This unit is designed for use as photo and video lighting only. It must not be used for other purposes and in particular not for domestic...
Overview Carrying handle Light effect pause / light effect Locking lever replay button | Fan switch Bowens S-Type connector Power socket LED continuous light Bluetooth®* switch / reset Umbrella holder Function button Light stand lock WiFi settings button Light effect knob On / Off switch V-mount battery adapter connection...
Seite 24
Overview WiFi symbol Group symbol Light effect symbol Bluetooth®* symbol Power symbol Power value symbol Colour temperature symbol Fan symbol Channel symbol...
Illuminance Measurement The measurement of unconcentrated light is standard without ref- lectors, the linear distance from the LED continuous light source to the illuminance meter is 1 meter. When the angle of incidence of the reflector becomes smaller and its depth deeper, the light is bundled. The centre of the light is very bright, the surrounding glow appears dimmed.
2 . Optional Battery Operation: The EF-150Bi can optionally be powered by the Jinbei EF- VM V-mount battery adapter. To do this, plug one end of the cable into the battery adapter and the other end into the...
Seite 27
Function Description Adjusting the Brightness Turn the function button [12] to adjust the brightness. The brightness range can be set between 1% and 100%, ”--“ means that the LED LED continuous light is switched off. Setting the Colour Temperature Briefly press the function button [12]. The symbol ”K“ now flashes in the display.
Seite 28
Function Description Preset Lighting Effects Turn the light effect knob [7] to enter the preset light effect mode. Turn the light effect knob [7] to set the desired light effect. The light effects continue to run continuously. Press the light effect pause / light effect replay button | fan switch [8] to pause or restart the selected effect. To exit the light effect menu, turn the light effect knob [7]. There are 10 preset light effects.
Seite 29
Wireless 2 .4 GHz Remote Control Briefly press the WiFi settings button [11], the WiFi symbol [15] flashes. By turning the function button [12], you can now activate or deactiva- te the WiFi connection of the EF-150Bi. Press the WiFi settings button [11] and use the function button [12] to set the group (GR) and channel (CH) one after the other.
”Jinbei” App / Bluetooth®* Download the ”Jinbei“ app for iOS from the App Store or the ”Studio“ app from the Amazon App Store for Android (iOS 9.0 or higher, And- roid 5.0 or higher). Connection with the Smartphone 1. Activate Bluetooth®* on your smartphone.
Seite 31
LED continuous light, the connection to the previous smartphone must first be interrupted and the LED continuous light must be de- leted from the settings in the app on the previous smartphone. *The Bluetooth® word mark and logos are registered trademarks of Bluetooth SIG, Inc. and any use of such marks by Jinbei is under licence. Other trademarks and trade names are the property of their respective owners.
Technical Data EF-150Bi Number of LEDs Power 170 W Energy efficiency class (EU 2017/1369) EU energy efficiency class spectrum A – G (EU 2017/1369) Colour temperature 2,700 – 6,500 K Colour rendering index (CRI) | Televi- 97 | 98 sion Lighting Consistency Index (TLCI) Power setting in % 0 –...
Seite 33
Technical details are subject to change without notice. Misprints and errors excepted. Re- production of these operating instructions – even in part – is not permitted. *The Bluetooth® word mark and logos are registered trademarks of the Bluetooth SIG, Inc. and any use of such marks by Jinbei is under licence. Other trademarks and trade names are the property of their respective owners.
Safety Instructions Danger from electric current! Faulty electrical installations or excessive mains voltage can cause electric shock. – Only connect the product if the mains voltage of the socket corre- sponds to the specifications on the type plate. – Connect the product to an easily accessible power outlet so that you can quickly disconnect it from the mains in case of problems. –...
Seite 35
Safety Instructions Caution! – Never use the mains cable as a carrying handle. – Keep the product and accessories away from naked flames, hot surfaces and easily flammable materials. – Lay the mains cable in such a way that it does not present a trip- ping hazard. – Do not bend the power cord or lay it over sharp edges. Caution! Danger for children and persons with limited physical, sensory or mental abilities (e .
Seite 36
Safety Instructions – Do not film car, bus, bicycle, motorbike or train drivers while driving this product. The driver may be blinded and cause an accident. This also applies to unlisted persons or groups if possible glare could cause an accident. – Do not shine directly into the eyes of people or animals as this may cause damage to the retina, visual disturbances and even blind- ness.
You are legally obliged to dispose of old devices separately from to dispose of household waste. Information on collection points that accept old appliances free of charge can be obtained from your local authority or town council. Conformity Herewith the RCP Handels-GmbH & Co. KG hereby declares that the radio system type „Jinbei EF-150Bi LED Continuous Light” complies with Directive 2014/53/EU. The complete text of the EU Declaration of Conformity can be downloaded at the following Internet address: https://www.jinbei-deutschland.de/en/egk/ef150bi RCP Handels-GmbH & Co. KG...
Seite 40
RCP Handels-GmbH & Co. KG In de Tarpen 42, D-22848 Norderstedt Germany Service Hotline: +49 40 270750400 www.jinbei-deutschland.de Item No.: 1098...
