Iso Connector - Caliber Rmd 030Bt Schnellstartanleitung

ISO connector:

B1. Rear right speaker(+)
B2. Rear right speaker(-)/ Purple-Black
B3. Front right speaker(+) / Grey
B4. Front right speaker(-)/ Grey-Black
B5. Front left speaker(+) / White
B6. Front left speaker(-) / White-Black
B7. Rear left speaker(+)/ Green
B8. Rear left speaker(-)/ Green-Black
A1. Not connected
A2. Not connected
A3. Not connected
A4. Battery 12V (+)/Yellow
A5. Antenna power/ Blue-White
A6. Not connected
A7. ACC+ I Red
A8. Ground / Black
c-
ANT eL
l
0eR
[.
Antenna input (DIN)
Warning: The negative speaker lead should NOT be grounded,
To connect the unit, use ISO connectors only.
If your vehicle isn't equiped with an ISO connector, please use the
provided ISO loom cable.This prevents an incorrect wired connection.
Damage caused by faulty wiring: warranty will be void.
We are continuously improving/updating
It's therefore possible that there is a slight
If something is different or not clear; always check our website for the most
/ Purple
B1 1
B21
A11
A21
CJ CJ
CJ CJ
CJ CJ
RCA output (White: Left/ Red: Right)
otherwise it will damage the radio!
WARNING!
our products and product information.
difference between the description in this
current
B31 B51 B71
BBi
B41 B61
A3I A5I A?I
M l A61 ABI
manual to the operation of the product.
version.
35 mm
