Fault
8. Water from the shower
or another appliance
connected to the lower
inlets drains off slowly.
Backflow from the
lifting station.

7. Technical data

Supply voltage
1 x 220-240 V - 10 %/+ 6 %, 50 Hz.
Power consumption
640 W.
Power factor
Cos φ 0.66 / 0.90.
Speed
-1
2800 min .
Rated current
3.1 A.
Insulation class
F.
Noise level
< 70 dB(A) to 12050-2.
Flow rate
Maximum 204 l/min.
System pressure
Maximum pump head: 8.0 m.
Maximum system head: 6.0 m.
The system pressure must not exceed 6 m
head to guarantee a sufficient drain of the
connected sanitary appliances.
Supply cable
2
1.2 m, 0.75 mm (H05VV-F-3G).
Net weight
6.6 kg.
Start and stop levels
Start level 1: 65 mm above floor level.
Start level 2: 115 mm above floor level.
Stop level: 35 mm above floor level.
10
Cause
a) The hydraulics are blocked.
b) The start level has changed.
c) The inlet pipe diameter is too
small.
Remedy
Check that the motor shaft can rotate
freely. Remove the motor flange to clean
the impeller.
Check and clean the float switch pipe.
Use a pipe with a larger diameter.
Liquid temperature
75 °C continuously (90 °C for 30 minutes).
Brine from a water softener: maximum 20 °C.
Brine
Maximum 15 % of salt.
Ambient temperature
+5 °C to +35 °C.
Duty
S3 - 50 % - 1 minute (30 seconds on; 30 seconds
off).
Marking
Approvals

8. Disposal of the product

This product or parts of it must be disposed of in an
environmentally sound way:
1. Use the public or private waste collection service.
2. If this is not possible, contact the nearest
Grundfos company or service workshop.
The crossed-out wheelie bin symbol on
a product means that it must be
disposed of separately from household
waste. When a product marked with this
symbol reaches its end of life, take it to a
collection point designated by the local
waste disposal authorities. The separate collection
and recycling of such products will help protect the
environment and human health.
