4

GENERAL DESCRIPTION

1. A shield
2. Handles
3. A body
4. A water tank
5. A grill
6. A heating element together
with a switch
7. Switch-key and temperature
regulator
8. Control lamp
9. Feet

TECHNICAL DATA

- power: 2000W
- voltage Supply: 230V ~ 50Hz

MOUNTING THE UNIT

Before the first use, unpack the unit and put particular
elements together.
Press the legs (B) into the holes in the lower part of the body
- fix the water tank (4). Attach the bowl's catches to the holes in
the body (3) and press it from the top
- accurately fix the heating element together with a switch (6) on
the body Slide the heating unit into holes in the tank (4), picture
01. Apply the switch – key into the body and press it.
- fix the grill (5)
- fix the shield (1) on the body (3)
USER'S MANUAL FOR
R
5
2
ELECTRIC GRILL GB21
6
1
3
5
8
7
6
picture 01
FOT. 2
9
