This universal remote control (2 in 1) is compatible with the majority of television sets, video
cassette recorders, DVD players and satellite recievers as well as DVBT sets (Digital Video
Broadcast Terrestrial) controlled by infra-red commands.
This remote control was programmed in the factory, so that you can use it to control most of
the sets of the THOMSON group's make. For this reason, we recommend that prior to
attempting to programme the remote control, you try it out by means of one of the methods
described in this user manual. However, first of all, you must install 2 batteries (AAA) in the
remote control.
Please keep this guide along with the code list (provided separately), so that you can
subsequently programme your remote control for use with other sets.
The keys
1 On/Standby or Standby only, depending on the
equipment being used.
2 Mode keys. Select the device to control (TV, VCR, ...).
3 Activation and use of teletext (Videotext).
4 Selection of channels, input of digital values,
channels with 2 digits, external TV/VIDEO sources
(AV connectors).
5 Zapping and commands or the muting of sound.
6 Programming of the remote control.
7 Activation and use of menus (display, deletion,
choice, confirmation).
8 Use of teletext (Fastext) or functions specific to
certain devices.
9 Operating a video cassette recorder (VCR) or a
DVD player (DVD).
Note: depending on the actual devices, manufacturers
and year of manufacture, the functions available will
vary.
DVBT (Digital Video Broadcast Terrestrial): for those
countries concerned, you can control a DVBT set by
programming separate codes by using the VCR/DVD
mode key.
Testing the remote control
before programming
1. Switch on the set you want to control.
2. Press the key that corresponds to the type of
equipment you want to control:
TV: television set,
VCR/DVD: video recorder - DVD player.
3. Direct the remote control towards the TV set and try
to switch it off by simply pressing the key B
device does not turn off, you must program the
remote control using one of the methods A, B, C or
D described hereafter.
Note 1: The VCR/DVD mode key can be
programmed to control another device other than
indicated on the key.. It is therefore possible, for
example, to allocate your Satellite mode to the
VCR/DVD mode key. You must enter the code
corresponding to the manufacturer and the device by
using one of the methods indicated in this manual.
However, method D (automatic search for a code)
will greatly simplify the task for you. In this case it is
only necessary to enter a code from the list that
corresponds to the type of device, for example: 603
for a Thomson satellite receiver) and then to run the
automatic search procedure. The remote control will
then test all the codes automatically until it finds those
that control the receiver.
Note 2: To control 2 devices of the same type and the
same brand (2 Thomson VCRs, 2 Thomson satellite
receivers, ...) ensure first that these two devices are
not set to react to the same sub code, they will require
one sub code for one and a different sub code for the
other (i.e., codes A and B with Thomson devices).
Once you have checked this, successively program 2
separate mode keys using method D.
manuals search engine
17:12 Page 1
Programming
the remote control
Method A – Fast programming
with 1-digit subcode
Before you start programming, you must find the
subcode of the set to be controlled.
Refer to the list provided with these instructions, page I
of the subcodes.
1. Switch on the set you want to control.
2. Hold down the S key until the key that corresponds
to the last mode you selected blinks 3 times and
then remains lit (the indicator light remains on for a
few seconds to give you the time to proceed with
the following steps. The indicator lamp flashes to
signal that this time is almost up, and then goes off).
3. Press the key that corresponds to the type of
equipment you want to control:
TV: television set,
VCR/DVD: video recorder - DVD player.
4. While the indicator is lit, type in the subcode
(example: 1 for THOMSON).
5. Direct the remote control towards the set and try to
switch it off by pressing the key B
6. If the set you want to control switches off, press OK
to memorise the subcode.
Note: If during step 3 you pressed the VCR/DVD key,
with identical sub-codes being used to control a VCR or
DVD player, pressing the B B key will turn off the type of
device you have chosen to control.
7. Should the set not switch off, press key B
repeatedly, until the set switches off. Between two
key presses, leave enough time for the key
corresponding to the selected mode enough time to
light up again (about 1 second). Proceeding this
way will enable you to see whether the set responds
or not.
8. Immediately upon the switching-off of the set to be
controlled, press OK to store the subcode.
Check of the programming:
B . If the
In principle, your set is ready for receiving the remote
control commands.
Check your remote control for proper functioning by
performing the test described on page 2.
Method B – 3-digit codes
programming
Before you start programming, you must find the code
of the set to be controlled.
Refer to the list provided with these instructions, page II
of the codes.
1. Switch on the set you want to control.
2. Hold down the S key until the key that corresponds
to the last mode you selected blinks 3 times and
then remains lit (the indicator light remains on for a
few seconds to give you the time to proceed with
the following steps. The indicator lamp flashes to
signal that this time is almost up, and then goes off).
3. Press the key that corresponds to the type of
equipment you want to control:
TV: television set,
VCR/DVD: video recorder - DVD player.
4. While the indicator is lit, enter the first digit of the
3-digit code proposed for the set to be controlled
(example: 036 for Thomson).
5. Direct the remote control towards the set and try to
switch it off by pressing the key B
1
B .
B
B .
