SPECIFICATIONS
LCD Screen
Sensor Resolution /
Interpolation
Optical Power (Magnification)
Illumination
Digital Zoom
Internal Storage
SD Cards Supported
Field of View
USB Cable
Image Format
Power Requirements
Weight / Dimensions
Operating Temperature

GETTING STARTED

BATTERY INSTALLATION

To use your microscope install 2AA batteries which provides the power to operate it
indoors or outdoors. Slide the battery cover on the bottom of the microscope (5) to
open, and insert the batteries according to the battery polarity as shown. After the
batteries are installed, close the battery cover. Battery condition will be shown in the top
left of the LCD in viewing and video modes, and "Low Battery Condition" will be shown
in red on the screen to notify you.
NOTE:
When not using the microscope, you will want to turn it off to preserve battery life. Typical battery life is 1.5 hours
using 3 LEDs and 0.75 hours using all 6 LEDs. For most applications, 3 LEDs are all that are needed for
proper illumination.
Also, if the microscope will not be used for a few weeks or more, remove the batteries.
4
| ENGLISH
2.4 inch /60 mm TFT
320 x 240 resolution
3MP CMOS Sensor 2048x1536 /
digital up to 12MP
1 to 3.7x and 54x with
digital zoom up to 216x
6 White LEDs
4x
128MB Flash Memory
(3MP – est. 250 Snapshots & 5min. Video)
Up to 16GB
26 mm @ 2x, 14 mm @ 3.7x, 2.5 mm @ 54x
2.0
Snapshots: JPG — Video: AVI
2AA Batteries (user supplied) 0.75W
6.6 oz (187 g) /
3.8" x 2.5" x 4.2" (96 x 63 x 107mm)
0°C to 40°C (32° F to 104° F)
