QUICK GUIDE MANUAL

Rear Panel

ON : Powers On/Off
1
DC-IN: Connects the detachable D/C power adapter.
2
LNB-IN : One satellite cable can be connected
3
Audio output : Connects to TV using RCA cable
4
Video output : Connects to TV using RCA cable
5
COAXIAL : Connects to a digital audio system using S/PDIF cable
6
HDMI : Connects to TV using a HDMI cable for both audio and video signals
7
Ethernet : Connects the set top box to network
8
USB : Connects the USB memory stick or external HDD
9

(D) Remote Control

5
6
2
1
8
3
4
opticum_axodin_manual_rev08.indd 10
1 2
10
18
9
12
14
7
11 13
15
4 5
3 4 6 7
19
25
29
21 23
26
17
16
28
24
20
22
8
9
31
35
36
30
33
27
32
34
