– Local operating restrictions – for example, in hospitals, aircraft, petrol stations or in the vicinity of people
with pacemakers – may apply. Electronic devices can potentially cause hazards or interference or be
subject to hazards or interference.
Information on maintenance and care
Clean all components with a damp cloth and do not use cleaning agents, scouring agents and solvents.
Store the device in a clean and dry place.
1 2
1 Base unit connection
2 Switch between front and side camera
3 Green LED for side camera
4 Red LED for side camera
Focal depth
1
The front camera on the DuoView camera delivers sharp images in a range between 3 and 5 cm from
the camera head. The side camera has a depth of field of 1 to 5 cm from the camera head.
Front camera illustration
Objects well beyond the focus range may appear blurred.
Connection for flexible cable
2
2.
3.
06
EN
3 5
4
< 3 cm
1.
5 Flexible cable
6
Side camera
7 Front camera
3 - 5 cm
6
7
> 5 cm
