01-55-960 | DOC-0018753 rev B | 10-2020
WALL SWIVELING FIXATION, PULL OUT
A2
A3
440 mm
B
17.32 in
A1
188 mm
C
7.40 in
www.schreder.com
Ansi3G
B
16 kg
GB + 1OB
32.2 lb
23 kg
GB + 2OB
kg/lb
50.7 lb
±1 kg
32 kg
GB + 3OB
70.5 lb
