TECHNICAL DATA

Impact Mechanism: "Rocking Dog"
Square Drive: 25 mm (1")
Free Speed: 3900 RPM
Max. Torque (Clockwise): 2034 Nm
Max. Loosening Torque (Counterclockwise): 2169 Nm
Air Consumption: 236 l/min
Working Pressure: 6.3 Bar (90 PSI)
Air Inlet Type: 1/4"
Recommended-Hose-Ø: 10 mm (3/8") (ID)
Noise Level: LpA: 95.71 dB (A) / LwA: 106.71 dB (A)
Vibration Level: ahd = 9.94 m/s² / K = 1.48 m/s²
Weigth: 14.4 Kg
Lenght incl. Square Drive: 550 mm
WARNING
Read, understand and follow all instructions and warnings before operating this tool.
Failure to do so may result in personal injury and/or property damage and will void

SAFETY INFORMATIONS

• Be sure the air tool is in OFF position when connecting tool to air supply.
• Always wear approved eye protection when using tools. If raising dust, wear a suitable mask.
• Use only accessories that are designed for use with tools. For example, with impact wrenches
do not use ordinary sockets. Use impact sockets for all air tools.
• Be sure to disconnect tool from air supply before changing accessories, performing service on
tool, and when not in use.
• As with any tool, use common sense when operating. Do not wear loose clothing or jewelry that
could become caught by moving parts, causing injury. Operate tool a safe distance from yourself
and others in the work area.
• Follow air source manufacturer information for connecting of regulators, filters, and other
accessories to air source. Do not install quick couplers directly on tool as they put unnecessary
strain on the air inlet threads possibly causing them to wear out prematurely. Instead, install
them on a short length of air hose attached to the tool.
• Keep children and other unauthorized persons away from the work area.
• Do not allow children to play with the tool or its packaging.
AIR SOURCE
Clean and dry air and a correct air pressure is recommended as air supply for this air tool.
Maximum of 90 PSI at the air tool is recommended for most air tools of this class. Check
specifications section for recommended pressure. (Depending on length of air hose and other
circumstances, air pressure at compressor may need to be increased to 100 PSI to ensure 90 PSI at
the tool. Water in the air hose and compressor tank contributes to reduced performance and damage
of the air tool. Drain the air tank and filters before each use and as necessary to keep the air supply
dry. Hose length over 25" causes loss in line pressure. Increase hose ID or increase compressor
pressure to compensate the pressure
pressure is critical.
BGS technic KG
Bandwirkerstr. 3
D-42929 Wermelskirchen
Air Impact Wrench
loss. Use an in-line pressure regulator with gauge if air inlet
Tel.: 02196 720480
Fax.: 02196 7204820
mail@bgs-technic.de
BGS 3240
warranty.
www.bgstechnic.com
