INTERCONNECTION
Please operate the tweeters only, when they are connected with the supplied in-line crossover.
Woofer

MOUNTING EXAMPLES

3er E46 Coupé door
3er E46 Sedan rear shelf
Optional: cut through the wire for a – 3dB tweeter level attenuation
Crossover
+
--
Signal input from the amplifier/signal source
3er E46 Sedan front door
3er E46 Convertible rear panel
ENGLISH
Tweeter
