1. IMPORTANT REMARK

Thank you for your confidence and for choosing our MIMO SG matrix. It is VERY IMPORTANT to carefully
read this manual, to fully understand its contents before any connection in order to maximize your use and get the
best performance from this equipment.
In order to guarantee the optimum operation of this unit, we strongly recommend that its maintenance be
carried out by our Authorized Technical Services.
All models of MIMO SG series come with a 3-year warranty.

1.1. Safety Precautions

This apparatus must be earthed through its mains cable.
Do not expose the unit to rain or water splashes, and do not place liquid containers or
incandescent objects like candles on top of the unit.
Should any connection / disconnection task be done, always disconnect the unit from the mains supply.
There are no user serviceable parts inside the unit.

2. INTRODUCTION

The MIMO SG is a series of fully programmable digital audio matrixes, with the following features:
•
8 (MIMO88SG) or 12 (MIMO1212SG) balanced MIC/LINE inputs (independent phantom power per
input channel).
•
8 (MIMO88SG) or 12 (MIMO1212SG) balanced LINE outputs.
•
8 (MIMO88SG) or 12 (MIMO1212SG) GPI control ports (General Purpose Input).
•
Programming and remote management via Ethernet using EclerNet Manager (or point to point, with
a direct CAT5 cable, or from an Ethernet network).
•
Remote control via UCP (User Control Panel) clients on Ethernet: simultaneous clients with
customized control panel, such as WPmSCREEN Ecler, Android®, iOS®, Windows®, etc.
•
Remote control from third party external devices. (Crestron, AMX, Vity, Medialon, etc. Registered
trademarks of their manufacturers). TP-NET protocol, via Ethernet or RS-232 ports.
•
Remote control bus for WPTOUCH digital panels and MPAGE16 messaging consoles (paging).
•
Configuration memory (presets) management.
•
Scheduled events based on calendar.
•
Extensive DSP available:
Routing matrix/mixer, from any input to any output with adjustable level for crossover points
o
(independent mixes of different inputs for each output).
Mono or stereo channel processing.
o
Level control, mute, vu-meters and phase adjustment for inputs and outputs.
o
Internal signal generator (sine wave, pink noise, white noise, polarity test).
o
Parametric EQ on inputs and outputs.
o
Delay on inputs and outputs.
o
Gate/compressor on input channels.
o
Compressor/limiter on outputs.
o
Input channel priority assignment (ducking).
o
Virtual and physical messaging consoles (paging).
o
Standard MIMO88SG / MIMO1212SG firmware version (for generic use) and alternative
o
version, for conferencing applications (MIMO88SG / MIMO1212SG CONFERENCE
version). Both firmware versions are compatible with the MIMO88SG / MIMO1212SG
hardware which can be freely updated with anyone of them.
The MIMO SG programming is done with EclerNet Manager*. Please refer to the EclerNet Manager
Software manual for more information.
* EclerNet Manager software is available on www.ecler.com.
4
