EXPLODED VIEW

Ref : FX8-G2-6
Ref : FX8-G2-10
Ref : FX8-G2-13
Before using your EDP, discover it inside out:
1. Handlebars
2. Left handle
3. Brake lever
4. Display
5. Left handle
6. Frien cable
7. Mast height adjustment ring
8. Lower tubular part of the mast
9. 3-hole clamping ring
10. Front suspension
11. Front LED lighting
12. Front mudguard
13. Front fork
14. Front tire
15. Front air chamber
16. Charging port
17. Calculator
18. Battery
19. Crutch
20. Rear tire
21. Drum brake
22. Rear LED lighting
23. Rear mudguard
24. Rear suspensions
25. Platform
26. Folding handle
27. Charger
