Live Screen - Eneo ISM-62F0028W0A Schnellinstallationsanleitung

Live Screen

NO Name
1 MFZ setup
2 Stream Change
3 Full Screen
4 Multi Window
5 OSD
6 Freeze
7 Mute
8 Duplex Audio
9 Snapshot
10 Print
11 Panic Record
12 Alarm
13 Stream Status
14 Storage Information
15 Date/Time
16 Event Status/Information
17
Description
Move to the MFZ screen. Manually sets the zoom/focus of the lens.
If selecting Dual Stream, the streams are shifted in the order of the 1st (the first stream) < 2nd (the second stream).
Displays the image in full screen.
Plays the video in two screens.
Display or hide the OSD menu on the screen.
Stops transmitting the image manually.
Used to mute the sound.
Delivers the sound to the camera by using a microphone connected to a PC.
Saves current image as .jpg image file.
Prints current screen.
Start the panic recording.
Turns on if an event occurs. It does not turn on if no reaction to the event is yet defined. Click this to check the
information of the event that occurred.
Click to display the network information.
Displays the storage information of the Micro SD Card.
Display the current time and date.
Click to see the event status, network information, streaming session, storage status, and system status.
A motion is detected by the connected camera.
EN
9
