EDIFIER GX07 Bedienungsanleitung

TRUE WIRELESS GAMING EARBUDS WITH ACTIVE NOISE CANCELLATION
Download EDIFIER CONNECT APP from the APP store/Google Play Store
EN
1. Product description and accessories
Button on the
charging case
Accessories:
Ear tips x 2 pairs, Storage bag x1, Brand sticker x1, Brand card x1,
Charging cable x1
Note:
• There are different size of ear tips attached in the package, please select
the suitable ones to wear.
• Images are for illustrative purposes only and may differ from the actual
product.
2. Power on/off
The earbuds will power on
when the case is opened.
3. Charge
Charge the earbuds
• Place the earbuds in the case and close the case for charging.
Charge the charging case
• Connect the case to power source with the included charging cable
for charging.
• Red light steady lit = charging
Red light off = fully charged
Battery level indicator on the charging case
• Open the charging case to show its battery level:
the ice blue light flashes three times at a normal speed: 66%~100%
the ice blue light flashes twic at a normal speed: 33%~66%
the ice blue light flashes once at a normal speed: 10%~33%
the red light flashes rapidly: low battery level, please charge the case
in time.
Battery level indicator (on both sides)
Warning: The rechargeable batteries that provide power for this product
must be disposed properly for recycling. Do not dispose of batteries in fire
to prevent an explosion.
4. User guide
Bluetooth connection
• Place the earbuds in the case, press and hold the button on the case for
around 3 seconds to enter Bluetooth pairing, and the ice blue light and
white light of the earbuds will flash alternately;
• Set mobile phone to search for and connect to "HECATE GX07", after
pairing is successful, the white light will be steady lit in music mode and
the ice blue light will be steady lit in game mode.
TWS pairing of the left and right earbuds & clear pairing records
Place the earbuds in the case, double click the button on the case to enter
the TWS pairing of the left and right earbuds and to clear pairing records,
and the white light will flash rapidly; After pairing is successful, the earbuds
will auto-enter Bluetooth pairing, and the ice blue light and white light of
the earbuds will flash alternately.
Functional operation
Accept/end a call: double click the left or right earbud
Noise cancellation mode switch: double click the left earbud
Sound mode switch: triple click the left earbud
Pause/play: double click the right earbud
Next track: triple click the right earbud
Note:
• Noise cancellation mode switch: noise cancellation mode(not available
when only one earbud is used), normal mode, ambient sound mode.
• Sound mode switch: music mode, game mode.
Wearing detection function
• Music control: Remove one earbud from ear to pause music; there will
be no action when insert earbud to ear (default state, the users can
customize settings through the EDIFIER CONNECT APP);
• Noise cancellation control: Insert the two earbuds to ears to enable noise
cancellation mode and remove to disable noise cancellation mode;
• You can also set or close the wearing detection function through the
EDIFIER CONNECT APP.
5. FAQs
When charging the charging case, the indicator is off .
• Please ensure the charging case is correctly connected with power source.
No sound
• Check if the earbuds are operating.
• Check if the earbuds volume are at an appropriate level.
• Check if the earbuds are correctly connected with mobile phone.
• Check if the earbuds are operating within a normal working range.
The call quality of the earbuds are not good.
• Check if mobile phone is in an area with strong signal.
• Please ensure the earbuds are within effective distance (10m) and no
obstacle between the earbuds and mobile phone.
When playing music, cannot control pause/play/next track via the
earbuds.
• Please ensure the paired device support AVRCP (Audio/Video Remote
Control Profile) profile.
The tapping function is too sensitive or not sensitive.
• Please ensure you are tapping within the effective area with a moderate
intensity or at an appropriate angle. You can also adjust to a desired
tapping sensitivity through the EDIFIER CONNECT APP.
After one earbud alone is connected to another mobile phone,
there is no sound from the other earbud when used again.
• When one earbud alone is connected to another mobile phone, the
interconnection between the left and right earbuds may have been
disconnected. To restore the two earbuds mode, double click the
button on the case to resume interconnection between the left and
right earbuds. Then try again.
There is a delay problem when playing game.
• Please triple click the left earbud to switch to game mode and then
start playing game.
Wearing detection function is not sensitive or too sensitive.
• To ensure every wearing of the earbuds by user can be recognized, the
recognition of wearing detection have been slightly raised. If they are
not used, please place the earbuds back into the case for charging and
storage; it is better not to place the earbuds alone in the pocket or on
the desk for long periods of time, so as to avoid interference with the
wearing detection function or missing of the earbuds. You can also set
the wearing detection function to other functions or close it through
the EDIFIER CONNECT APP.
6. Maintenance
• If it is not used for long periods of time, please charge the product with
lithium battery every three months.
• Keep the product away from humid places to avoid affecting internal
circuit. Do not use the product during intense exercise or with much
sweat to prevent sweat from dropping into the product to make damage.
• Do not put the product in places exposed to sun or with high temperature.
High temperature will shorten service life of electronic components,
damage battery and make plastic components deformed.
• Do not put the product in cold places to avoid damaging internal circuit
board.
• Do not dismantle the product. Non-professional personnel may damage
the product.
• Do not drop, strongly vibrate, strike the product with hard object to avoid
damaging internal circuit.
• Do not use drastic chemicals or cleaner to clean the product.
• Do not use sharp objects to scratch product surface to avoid damaging
shell and affecting facade.
Model: EDF700012
Edifier International Limited
P.O. Box 6264
General Post Office
Hong Kong
www.hecategaming.com
Designed by DONGGUAN EDIFIER ESPORTS TECHNOLOGY CO., LTD.
www.edifier.com
2021 Edifier International Limited. All rights reserved.
Printed in China
NOTICE:
For the need of technical improvement and system upgrade, information
contained herein may be subject to change from time to time without
prior notice.
Products of EDIFIER will be customized for different applications. Pictures
and illustrations shown on this manual may be slightly different from actual
product. If any difference is found, the actual product prevails.
The ice blue light flashes.
Indicator
Tap zone
The earbuds will power
off when placed in the
case and the case is closed.
Input:
5V 200mA (earbuds)
5V 1A (charging case)
HECATE GX07
