CONNECTIONS, OPERATING AND DISPLAY ELEMENTS

1 DMX IN / OUT RJ45
DMX inputs and outputs with an RJ45 interface for receiving data and controlling DMX devices.
The device has 1 DMX universe that can optionally be routed to one of the 4 wire pairs. The +
and – contacts are intended for both DMX input and DMX output.
Pin assignment:
5
1
Wire pairs
Contacts
polarity
1
2
3
4
5
6
7
8
3
4
2
&
1+
1-
2+
3-
3+
2-
4+
4-
