SCANGRIP NOVA-EX R Bedienungsanleitung Seite 2

WARNING!
Battery Pack:
• Only use the battery pack from Scangrip A/S, Part No. 31300090
Model No.: ZJ18650 21.6V 3350mAh 72.36Wh
• Only use the charger pack with spec of Input: AC100-240V/50-60Hz 0.8A Output: 25.2V 1.5A
• Using other sources parts may lower the intrinsic safety level of the explosion-proof lights. Make sure
charging in non-dangerous environment.
1. STANDARD
IEC 60079-0:2017 Explosive atmospheres 一 Par0:Equipment 一 General requirements
IEC 60079-1:2014 Explosive atmospheres 一 Par1:Equipment protection by flameproof enclosures "d"
IEC 60079-7:2015 Explosive atmospheres 一 Par7:Equipment protection by increased safety "e"
IEC 60079-18:2014 Explosive atmospheres 一 Par18:Equipment protection by type of protection "m"
IEC 60079-11:2012 Explosive atmospheres 一 Par11:Equipment protection by intrinsic safety "i"
IEC 60079-28:2014 Explosive atmospheres 一 Par28:protection of equipment and transmission systems using
optical radiation
IEC60079-31:2013 Explosive atmospheres 一 Par31: Equipment dust ignition protection by enclosure"t"
IEC 60529:2001 Degrees of protection provided by enclosure(IP code)
2. Product Model Definition and Basic Parameters
Product Model Definition
Rechargeable Work Light NOVA-EX R 03.5618
Basic Parameters: Table 1.
Table 1: Light Design Parameters
Product Description:
Product Model No.:
Dangerous Area:
Charger:
Battery Type and Capacity:
Power Rating:
Explosion-proof Symbol:
Luminous Flux:
Working Time:
CRI (Ra):
CCT:
IPXX:
Operation Temperature(°C):
Storage Temperature(°C):
Product Dimension:
Product Weight:
Product Model NO.
Product Description
Rechargeable Work Light
NOVA-EX R 03.5618
Zone 1、 Zone 2/ Zone 21、 Zone 22
DC25.2V 1.5A
21.6V/ 3350mAh 72.36Wh (Li-ion)
31W
II 2G Ex db eb mb IIC T6 Gb / II 2D Ex tb IIIC T85°C Db IP65
High 4000lm
High 2.15h
>90
6000K
IP65
-20°C~+45°C
-20°C~+45°C
L270*W261*H130mm
4.3Kg
