RF RC M30 / RF HS M30 SW868/SW915/SW917/SW922
//
Montage- und Anschlussanleitung / Funkschalter
Mounting and wiring instructions / Wireless switch
Instructions de montage et de câblage / Interrupteur sans fil
Istruzioni di montaggio e collegamento / Interruttore wireless
Instruções de montagem e instalação / Interruptor de rádio frequência
Инструкция по монтажу и подключению / Радио-выключатель
English
Design of wireless range
The radio signal is attenuated on the way from the transmitter to
the receiver. In addition, the radio signal is attenuated/influenced by
obstacles. The degree of attenuation depends on the material of the
obstacle. The following tables serve as a guide.
Penetration of radio signals:
Material
wood, gypsum, glas uncoated
brick stone, press boards
armoured concrete
metal, aluminium lamination, water
Typical ranges:
Place of use
in free field (SW868/915/917)
in free field (SW922)
indoors (SW868/915/917)
indoors (SW922)
Field strength meter for range test:
Transmitter Device
SW868 swView 868 MHz
SW915 swView 915 MHz
SW917/SW922
Radio operation
The transmission of a switching command from the transmitter to the
receiver takes about 80 to 100 ms, based on the sWave® data
transmission. The switching signal of a transmitter must not be
generated at a shorter distance, otherwise this signal will be
overlooked. The receiver must support the sWave® protocol of the
steute modules. Each switching operation triggers a transmission
from the radio unit.
Allocation of locations and radio frequencies:
Device type Radio frequency
SW868 868.3 MHz
SW915 915.0 MHz
SW917 917.0 MHz
SW922 916.5 MHz
Penetration
90...100%
65...95%
10...90%
0...10%
Wireless range
(approx.)
450 m
150 m
40 m
20 m
Material No.
1190393
1221794
on request
Place of use according to
EU 2014/53/EU (RED)
USA FCC
Canada IC
Mexico IFT
Brazil ANATEL
Japan ARIB STD-T108
Mounting notes
Fix the wireless switch to a suitable medium and a through-hole with
two nuts. Do not use ferromagnetic material. Install the actuator at a
minimum distance of 8 mm to ferromagnetic material. In special
cases, perform a functional test. The tightening torques are low, see
technical data. The sensor part is sensitive to strikes: do not use the
front as an end stop.
Battery replacement
See section »Battery replacement«.
Safety
Do not use the device in connection with other devices whose direct or
indirect purpose is to ensure life or health, or whose operation may
pose a threat to humans, animals or material assets.
N.B.
The electrical connection may only be carried out by authorised
personnel. Subject to technical modifications. Reconstruction and
alterations to the device are not allowed. steute does not assume any
liability for recommendations made or implied by this description. New
claims for guarantee, warranty or liability cannot be derived from this
document beyond the general terms and conditions of delivery.

Maintenance

With rough conditions, we recommend routine maintenance as follows:
1. Removal of all dirt particles.
Cleaning
- In case of damp cleaning: use water or mild, non-scratching,
non-chafing cleaners.
- Do not use aggressive cleaners or solvents.
Clean enclosure on the outside only. Clean enclosure with household
cleaning agents. Do not use compressed air to clean.
Disposal
- Observe national, local and legal regulations concerning disposal.
- Recycle each material separately. Dispose of possibly contained
batteries correctly.
