Features
• User-selectable Ultra-fast and Eco charging modes
• Individual charging of 1–4 pcs of AA / AAA NiMH batteries
• Charging Termination : negative delta V, safety timer & temperature cut-off protections
• Tri-color LED indication (Blue, Green & Red) for charging conditions and system statuses
• Trickle charge
• Built-in, integrated AC power supply
• High efficiency, low noise cross-flow cooling fan
Read the instruction manual thoroughly before use. Keep the manual for future reference.
Charging Instructions
1. Connect AC power cord to the battery charger (Fig. 1a).
2. Plug the other end of AC power cord into a wall socket (Fig. 1b).
3. Slide to open the battery cover. And insert 1-4pcs NiMH batteries into the battery charger according to the battery polarity
(Fig. 2). The Blue and Green LEDs will flash alternatively.
4. Slide to close the battery door and press the button (within 5 seconds) to select the Ultra-fast or Eco charging modes (Fig. 3).
- Ultra-fast charging mode: Used for or maximum charging speed. (Approx. charging time to charge up 90%
capacity of Charge 10 AA 1700mAh batteries in 20°C operation temperature: 10 minutes)
- Eco charging mode: Provide a comfort charging conditions for battery which helps to prolong the battery
life-cycle.
5. Charging will commence and the LED indicator will show the charging status of the batteries.
- In Ultra-fast charging mode, the blue LEDs will be flashing when the batteries are charging. And they stay solid when the
batteries are fully charged. For over-discharged, aged or idle batteries for months, recommend to charge and reactivate
batteries by Eco charging mode.
- In Eco charging mode, the green LEDs will be flashing when the batteries are
charging. And they stay solid when the batteries are fully charged.
- For bad or single-use batteries, the LEDs will flash red rapidly. Remove these batteries
from the charger.
- For over-temperature warning, Blue-red or Green-red LEDs will be flashing according to Ultra-fast charging
mode or Eco charging mode. Recommend to charge the batteries on or below 33°C.
- For system warning, Red, Blue and Green LEDs will flash alternatively. Please disconnect and resume the
power to restore operation.
6. Once batteries are fully charged and LED stays solid, slide to open battery to remove the batteries and disconnect the battery
charger from the power supply.
For best performance, always use GP NiMH Charge 10 Ultra-fast 1700mAh batteries.
Usage tips
• It is normal for batteries to become hot during charging and they will gradually cool down to room temperature after fully
charged.
• Remove batteries from the electrical device if the device is not going to be used for a long time.
• Charger storage temperature: -20 ~ +35°C.
• Charger operation temperature: 0 ~ +33°C.
• Charging time is based on the same battery size and capacity at ambient temperature (25°C).
• The sliding battery cover is to protect the user from accessing the batteries at high temperatures during charging. Open the
sliding battery cover will stop the charging immediately.
• If the over-temperature warning persists after moved the charger to a lower temperature environment (20-25°C), suggested
replacing the battery(ies) or buying or using the GP Charge 10 battery(ies) instead.
• When AA and AAA batteries are mixed for charging, the charger will charge the AA battery (ies) and then followed by the AAA
battery(ies). The charging time may be longer than the charging table mentioned.
After completed the charging, the fan will continue to cool down the battery for few minutes.
Suggest the user remove the batteries after the fan stops.
Safety information
• This charger is designed to charge NiMH batteries only. Do not use non-rechargeable, LiFePO4, NiCd or Li-ion batteries. Charging
other batteries may lead to explosion, battery rupture or leakage, personal injury or property damage.
• This charger is designed for indoor use only. Do not expose the charger to rain, snow or direct sunlight.
• Do not use the charger in humid conditions.
• Make sure the charger is used between 0~33°C.
• Do not use the charger if the plug is damaged.
• Do not use the charger after it has been dropped or damaged.
• Do not open/disassemble the charger.
• In case a battery sleeve is damaged, do not use it in the charger.
• Never remove the outer sleeve from batteries.
• Please use the charger in a well-ventilated place and ensure there are no other items covering the charger to avoid
overheating. Do not stack-up multiple chargers while charging.
• This charger is maintenance-free but should be wiped clean regularly with a dry and soft cloth. Do not use abrasives or
solvents. Unplug the charger before cleaning.
• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including interference that may cause undesired operation.
Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities. Contact your local government for information
regarding the collection systems available. If electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into the groundwater
and get into the food chain, damaging your health and well-being.
GB
