8. Trouble Shooting

The TC 1 S was checked and controlled by the manufacturer according to strictest quality standards.
Should however arise problems, please fi rst examine the appliance by utilizing with the following list.
Disturbance/Operating error
After connection of the device no indication:
Only horizontal lines in the indication of measured values:
Wrong zero point compensation: values too high in the
indication of measured values:
„Over" in the indication.
„Charge battery" in the indication.
All manuals and user guides at all-guides.com
Monitoring points/Remedy
• Battery flat, connect with network adaptor 230 VAC/secondarily 24 VDC
for 14-16 hours to charge the internal batteries of the appliance.
• Sensor resp. measuring cable at sensors of 4 to 20 mA not connected
or defective.
Please check whether the sensor or the cable is being the cause of the
trouble. Please change both of the parts one after the other.
• Zero point correction was carried out with sensor being under pressure
resp. force. Repeat compensation of zero point correction as described
on page 11 / paragraph 2.3
• Entry of measuring range was exeeded
- Short circuit of sensor or cable
- pressure measuring cell was mechanically overcharged (overstressed)
• Over the external socket the batteries of the measuring instrument can
be charged with a Klauke network adaptor (230 VAC, secondarily 24
VDC or an external voltage of 24 VDC and max. 30 VDC stabilized)
Recommended charging time: 14-16 hours.
