English
The tube cleaning kit is suited for high-pressure cleaners by Top Craft and King
Craft. It is ideally suited for the cleaning of tubes and discharges with a diameter of
at least 40 mm (1.5") and a radius of at least 70 mm (1.5").
The tube cleaning kit is not suited for the commercial use.
Packing list
1 Tube cleaning kit
A – Nozzle
B – Coupling
2 Adapter
Usage of the adapter
Use the tube cleaning kit without adapter for
– Top Craft high-pressure cleaners, model 2004 and later
– King Craft high-pressure cleaners, model 2004 and later
Use the tube cleaning kit and the adapter for
– Top Craft high-pressure cleaners, model 2001 – 2003
– King Craft high-pressure cleaners, model 2000 – 2003
Use the tube cleaning kit and the adapter with a spray lance extension for
– Top Craft high-pressure cleaners, model 2000
– King Craft high-pressure cleaners, model 1997 – 1999
Note: If the adaptation is difficult to move apply Vaseline or silicon grease to the O
ring on the adapter.
Application
1a. Press the coupling of the tube cleaning hose into the bayonet connection of
the high-pressure gun.
1b. Turn the coupling part by 90° until it locks into place.
2. Insert the nozzle of the tube cleaning hose up to the red marking in the tube
to be cleaned.
3. Press the lever of the high-pressure gun, turn on the high-pressure cleaner
and manually guide the tube cleaning hose with the automatic advance.
• If the tube cleaner encounters a clogged spot: Press the lever of the high-
pressure gun repeatedly and release again.

Safety instructions

Please observe the safety instructions of your high-pressure cleaner.
The tube cleaning kit must not be used by children.
Only trigger the high-pressure jet when the nozzle has been inserted
into the tube to be cleaned at least up to the red marking.
Never pull the tube cleaning hose completely out of the tube to be
cleaned during the high-pressure operation.
If the cleaning operation has been completed turn off the high-pressure
cleaner and disconnect the tube cleaner from the high-pressure gun.
