EN
Disclaimer and Warning
Congratulations on purchasing your new DJI OSMO
use. Failure to read and follow instructions and warnings may result in serious injury to yourself or others, damage to your DJI OSMO product, or damage to other
objects in the vicinity. By using this product, you hereby signify that you have read this document carefully and that you understand and agree to abide by all terms
and conditions of this document and all relevant documents of this product. You agree to use this product only for purposes that are proper. You agree that you are
solely responsible for your own conduct while using this product, and for any consequences thereof. DJI OSMO accepts no liability for damage, injury or any legal
responsibility incurred directly or indirectly from the use of this product.
DJI is a trademark of SZ DJI OSMO TECHNOLOGY CO., LTD. (abbreviated as "DJI OSMO") and its affiliated companies. Names of products, brands, etc., appearing
in this document are trademarks or registered trademarks of their respective owner companies. This product and document are copyrighted by DJI OSMO with all
rights reserved. No part of this product or document shall be reproduced in any form without the prior written consent or authorization of DJI OSMO.
This document and all other collateral documents are subject to change at the sole discretion of DJI OSMO. For up to date product information, visit http://www.dji.
com and click on the product page for this product.
This document is available in various languages. In the event of divergence among different versions, the English version shall prevail.
Introduction
When used with the high-bright remote monitor, the DJI Ronin 4D Video Transmitter can be installed on the back panel of DJI Ronin 4D to transmit video and control
signals wirelessly.
Usage
Installation
1. Press the battery eject button and remove the Intelligent Battery. (Figure A)
2. Remove the four M4×19 screws on the battery compartment and remove the battery compartment. (Figure B)
3. Install the four antennas on the video transmitter. (Figure C)
4. Install the video transmitter on Ronin 4D and tighten three M4×19 screws. (Figure D)
5. Install the battery compartment on the video transmitter and tighten the two M4×19 screws. Reinsert the Intelligent Battery into the battery compartment. (Figure E)
Linking
To start linking, hold the Link button on the video transmitter or go to Settings on the high-bright main monitor, tap Video Transmission, and then Pairing. The linking
status indicator blinks red and green alternately.
4
1
Linking Status Indicator
对频状态指示灯
配對狀態指示燈
リンクステータス インジケーター
연동 상태 표시등
Kopplungsstatusanzeige
Indicador de estado de enlace
Voyant d'état de l'appairage
Indicatore di stato del collegamento
Indicator koppelingsstatus
Indicador de estado de ligação
Indicador de status de vinculação
Индикатор статуса сопряжения
TM
product. Please read this entire document and all safe and lawful practices DJI OSMO provided carefully before
2
Link Button
Firmware Update Port (USB-C)
对频按键
固件升级接口（USB-C）
配對按鈕
韌體升級連接埠 (USB-C)
リンクボタン
ファームウェア更新ポート(USB-C)
펌웨어 업데이트 포트 (USB-C)
연동 버튼
Kopplungstaste
Anschluss zur Firmware-Aktualisierung (USB-C)
Botón de enlace
Puerto de actualización del firmware (USB-C)
Bouton d'appairage
Port de mise à jour du firmware (USB-C)
Pulsante di collegamento
Porta per aggiornamento del firmware (USB-C)
Koppeltoets
Firmware updatepoort (USB-C)
Botão de ligação
Porta de atualização de firmware (USB-C)
Botão de vinculação
Porta de atualização de firmware (USB-C)
Кнопка сопряжения
Порт обновления прошивки (USB-C)
3
