Connections to EVC 2. Fig G
4 CPM Y-split, 6-pin
5 AUX termination plug
7
Standard EVC bus, 6 pin
NOTICE!
The CPM unit may not be connected to
NOTICE!
No switch should be able to cut the power. The power supply
should be located directly on the battery. Refer to the
wiring diagram, Fig. C.
14. Connect the black cable to the battery negative terminal.
Refer to Fig. B.
15. Autoconfigure the system and delete any fault codes.
any of the start batteries.
