3 Luminaire Assembly

Visual color evaluations can also be performed with a luminaire set up in a des-
ignated „color evaluation area".
Suspend the luminaire with snap hooks (and chains) over the work area.
Place diffuser pins in brackets, rougher glass facing towards lamps. Snap dif-
fuser latch.
Connect several luminaires in a chain with cascade cables (refer to full manual
for detailed settings). Ready to plug in and turn on!
Setup Recommendations
Please see SAE J361 for set-up of designated „color evaluation area".
Keep 30 cm distance to wall/ceiling or next luminaire.
Each luminaire needs adequate support, at least 50 kg.
Provide 1150 W per luminaire and follow local electrical regulations.
