4.

TS 600 beltpack transmitter

4.1

Controls and indicators

Transmitting antenna.
Battery status LED to indicate the power on-off and battery status.
(a) When the beltpack transmitter is switched on this LED will flash for a moment to indicate the
normal battery status.
(b) When the LED stays red after having switched on the transmitter the battery is too weak and
must be replaced.
On-off switch (ON = switch to "ON"-position; OFF = switch to "OFF"-position).
Switch off the transmitter when not in use.
AF input, 4-pin mini XLR for microphones (lavalier, neckworn mics).
For connection please refer to chapter 4.5 AF Connection.
Infrared receiving diode for ACT function.
Gain control to adjust input gain.
Opus 600 – TS 600 Beltpack Transmitter
