WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ1 All manuals and user guides at all-guides.com ELECTRON WB-100MA/W INSTRUCTI (REMOTE DISPLAY VERSION) Please read carefully and reference.
Seite 2
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ2 All manuals and user guides at all-guides.com...
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ4 All manuals and user guides at all-guides.com Applications • This equipment has been calibrated as a precision weighing instrument and can be used to certify weights and/or business transactions. • It can be used to obtain reference data during medical examinations, such as periodic checkups, and can help the prevention of obesity.
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ6 All manuals and user guides at all-guides.com 1.Product Assembly and Components Product Components Please verify that the following components are in the package. (Remote Display Version) Accessories AC Adapter MODEL:A30930G Display Box Battery Compartment Platform...
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ8 All manuals and user guides at all-guides.com 2.Preparation for Use Level Adjustment (Remote Display Version) For accurate measurement, place the unit on as flat a surface as possible and adjust the level with the adjustable feet so the bubble in the level gauge is in the center of the frame.
Seite 6
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ10 All manuals and user guides at all-guides.com 3.Operating Instructions 1. Standard Weighing Procedures 1. Turn on the power by pressing the key. 2. After all the segments flash, [0.0kg] is displayed. 3. Step onto the center of the scale platform.
Seite 7
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ12 All manuals and user guides at all-guides.com 4. RS-232C Communication Specifications ■ Specifications ■ Names and connection methods for signal lines Terminal no. Signal name Communication standard EIA RS-232C Communication method Asynchronous method Signal speed...
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ14 All manuals and user guides at all-guides.com Specifications TYPE WB-100MA WB-110MA AC adapterCentre minusMODEL A30930GCLASS 2 Input Voltage : 230VAC50Hz65mA Output Voltage : 9VDC±0.45VDC Power Source Rated Current : 300mA No Load Input Voltage : 12VDC±0.6VDC...
Seite 9
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ16 All manuals and user guides at all-guides.com...
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ18 All manuals and user guides at all-guides.com Anwendungen • Diese Waage ist ein Präzisionsinstrument, das für den privaten und kommerziellen Gebrauch konzipiert wurde. •Bei ärztlichen Untersuchungen, wie regelmäßigen Check-ups, liefert das Gerät Bezugsdaten und hilft beim Vorbeugen von Fettleibigkeit.
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ20 All manuals and user guides at all-guides.com 1.Produktaufbau und Komponenten Produktkomponenten In der Packung sind folgende Komponenten enthalten. (Modell Remote Display) Zubehör AC-Adapter: MODELL: A30930G Anzeigegerät Batteriefach Wiegeplattform Bundschrauben für Schelle (x 2) Bedienungsanleitung Höhenregulierer Einstellbare Füße...
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ22 All manuals and user guides at all-guides.com 2.Vorbereitungen vor Gebrauch Höheneinstellung (Modell Remote Display) Um ein genaues Messergebnis zu ermöglichen, positionieren Sie das Gerät auf einem möglichst ebenen Untergrund und stellen Sie die Höhe mittels der verstellbaren Füße so ein, dass sich die Blase des Höhenregulierers in der Mitte des Rahmens...
Seite 13
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ24 All manuals and user guides at all-guides.com 3.Betriebsanleitungen 1. Normales Wiegen 1. Stellen Sie das Gerät mittels der Taste ein. 2. Die einzelnen Segmente blinken auf und es erscheint [0.0kg] auf der Anzeige. 3. Steigen Sie auf die Plattform.
Seite 14
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ26 All manuals and user guides at all-guides.com 4. RS-232C Kommunikationsspezifikationen ■ Spezifikationen ■ Signalleitungen und Verbindungsmethoden Anschluss Nr. Signalbezeichnung Kommunikation Norm EIA RS-232C Kommunikationsmethode Asynchron-Methode Signalgeschwindigkeit 2.400 Baud Datenbitlänge 7 bit Parität GERADE Stoppbit 1 Bit •...
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ28 All manuals and user guides at all-guides.com Spezifikationen WB-100MA WB-110MA AC-Adapter Centre minus MODEL A30930GCLASS 2 Eingangsspannung : 230VAC50Hz65mA Ausgangsspannung : 9VDC±0,45VDC Stromquelle Nennstrom : 300mA Leerlauf-Eingangsspannung : 12VDC±0,6VDC LR6 (AA Alkali-Batterie) x 6, (nicht im Lieferumfang) Stromverbrauch Max.
Seite 16
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ30 All manuals and user guides at all-guides.com...
Symboles d’avertissement Le présent manuel d’utilisation contient divers symboles d’avertissement visant à garantir une utilisation correcte et sans risque de la balance Tanita BWB-800MA, afin de vous éviter ainsi qu’à d’autres utilisateurs tout dommage physique ou matériel. Ces symboles sont expliqués ci-dessous. Nous vous conseillons de vous familiariser avec eux avant de parcourir le manuel d’utilisation.
Seite 18
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ34 All manuals and user guides at all-guides.com 1.Assemblage du produit et composants Composants du Produit L'emballage contient les composants suivants : (Version Avec Téléaffichage) Accessoires Adaptateur secteur CA: MODELE:A30930G Boîtier Compartiment à piles Plate-forme Vis de fixation du...
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ36 All manuals and user guides at all-guides.com 2.Avant l'utilisation Réglage du niveau (Version Avec Téléaffichage) Pour effectuer des pesées précises, placez la plate-forme sur une surface aussi plane que possible, puis réglez son niveau grâce aux pieds ajustables, de sorte que la bulle visible dans l’indicateur de niveau se trouve exactement au centre du...
Seite 20
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ38 All manuals and user guides at all-guides.com 3.Fonctionnement 1. Procédures pour une pesée standard 1. Mettez lÅfappareil en marche en appuyant sur la touche 2. [0.0kg] s’affiche, une fois que tous les segments se sont allumés 3.
Seite 21
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ40 All manuals and user guides at all-guides.com 4. Caractéristiques pour commutation RS-232C ■ Caractéristiques techniques ■ Appellation et méthodes de connexion pour les lignes de signaux Numéro de broche Nom du signal Norme de commutation EIA RS-232C Méthode de commutation...
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ42 All manuals and user guides at all-guides.com Caractéristiques TYPE WB-100MA WB-110MA Centre de l'adaptateur CA moins MODELE A30930G CLASS 2 Tension d'entrée : 230VAC50Hz65mA Tension de sortie : 9VDCÅ}0.45VDC Alimentation Courant nominal : 300mA Tension d’entrée hors charge : 12VDCÅ}0.6VDC LR6 (AA pile alcaline) x 6, (Non fournies) Consommation d'électricité...
Seite 23
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ44 All manuals and user guides at all-guides.com...
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ46 All manuals and user guides at all-guides.com Applicazioni • Questo apparecchio è stato calibrato come uno strumento di pesatura di precisione e può essere utilizzato per certificare pesi e/o transazioni commerciali. • Può essere utilizzato per ottenere dati di riferimento durante esami medici, come i check-up periodici, e può assistere nella prevenzione dell’obesità.
Seite 25
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ48 All manuals and user guides at all-guides.com 1.Montaggio prodotto e componenti Componenti prodotti La confezione contiene i seguenti componenti: (Tipo Con Display Separato) Accessori Adattatore CA MODELLO: A30930G Scatola display Vano batterie Pedana 2 viti di fissaggio per...
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ50 All manuals and user guides at all-guides.com 2.Preparazione per l’uso LRegolazione del livello (Tipo Con Display Separato) Per effettuare la misura con precisione, mettere l’unità sopra una superficie più piatta possibile e regolare il livello con i piedini regolabili così...
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ52 All manuals and user guides at all-guides.com 3.Istruzioni per il funzionamento 1. Procedura di pesatura standard 1. Accendere l’alimentazione premendo il tasto 2. Quando tutti i segmenti smettono di lampeggiare, sul display appare [0,0Kg]. 3. Salire sulla pedana, in posizione centrale.
Seite 28
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ54 All manuals and user guides at all-guides.com 4. Dettagli comunicazione RS-232C ■ Dettagli ■ Nomi e metodi di connessione per le linee di segnale Terminale n. Nome segnale Comunicazione Standard EIA RS-232C Metodo di comunicazione Metodo asincrono Velocità...
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ56 All manuals and user guides at all-guides.com Caratteristiche tecniche TIPO WB-100MA WB-110MA Adattatore CA Centro meno Modello A30930G CLASS 2 Tensione entrata: 230 VCA 50 Hz 65 mA Tensione uscita: 9 V CC ± 0,45 V CC...
Seite 30
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ58 All manuals and user guides at all-guides.com...
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ60 All manuals and user guides at all-guides.com Funciones • Este equipo ha sido calibrado como instrumento de precisión y puede ser usado para certificar pesos y/o transacciones comerciales. • Puede ser usado para obtener datos de referencia en exámenes médicos, por ejemplo en revisiones periódicas, y puede ayudar a prevenir la obesidad.
Seite 32
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ62 All manuals and user guides at all-guides.com 1.Montaje de la báscula y componentes En la caja de embalaje se incluyen los siguientes componentes: (Versión de Indicación Remota) Accesorios Adaptador de CA modelo A30930G Display Compartimiento para las pilas Plataforma Tornillos de sujeción del...
Seite 33
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ64 All manuals and user guides at all-guides.com 2.Preparación para el uso de la báscula Nivelación (Versión de Indicación Remota) Para obtener una medición precisa, sitúe la unidad en una superficie lo más plana posible y regule el nivel, ayudándose de las patas ajustables con objeto de que la burbuja del indicador de nivel se sitúe en el centro del marco.
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ66 All manuals and user guides at all-guides.com 3.Instrucciones de funcionamiento 1. Procedimientos de pesado estándar 1. Conecte el interruptor principal con la tecla 2. Después de que destellen todos los segmentos, aparece [0.0 kg]. 3. La persona a pesar debe pararse sin moverse en el centro de la balanza.
Seite 35
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ68 All manuals and user guides at all-guides.com 4. Especificaciones del sistema de comunicación RS-232C ■ Especificaciones ■ Nombres y métodos de conexión de las líneas de señales Terminal Nº Nombre de la señal Comunicación norma EIA RS-232C Método de comunicación...
Seite 36
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ70 All manuals and user guides at all-guides.com...
Seite 37
WB-100MA-取説/04.01.27 04.1.28 9:12 AM ページ72 All manuals and user guides at all-guides.com Especif TIPO Fuente de alimentación Consumo eléctrico Sistema de medición Medición de peso Capacidad máxima/ ajuste mínimo Precisión en la primera calibración Datos de entrada Talla Peso Datos de salida...
