Installation manual
You can always find the most up-to-date version of the installation manual on
www.doorbird.com/support
Components
Contents
1x DoorBird Vdeo Door Station
1x Power supply unit (mains adaptor) with four country-specific adaptors
1x Cable with plug for the power supply (black, red)
1x Cable with plug and RJ45 jack for the network cable (white-orange, orange, white-green,
green)
1x Cable with plug for the network cable (white-orange, orange, white-green, green),
alternatively to the cable with plug and RJ45 jack
1x Cable with plug for the electric door opener (purple, purple)
1x Cable with plug for the electric door chime (blue, blue)
1x Cable with plug for the door-opening button (yellow, yellow)
Several crimp connectors
4x Phillips countersunk head screws for the wall mounting plate, long
4x Phillips countersunk head screws for the wall mounting plate, short
4x Dowels
1x Safety screw
1x Screwing-tool for the safety screw
1x Wall mounting plate with sealing ring (installation on wall
1x Installation manual
1x Quick start guide
Video door station - front
surface)
1
