2.1 Specification

Indicators Items
Product size 71.7x26.0x44.9in(182x66x114cm)
Dimensions
Packing size 57.5x9.8x31.5in(146x25x80cm)
Frame Material Aluminum
Type Brushless
Motor
Power 250W
Type Lithium
Capacity 36V15AH
Balance,over-charge,under-voltage,
Battery
Management
overheating,automatic shutoff
Watt hours 450WH
Derailleur L-TWOO 9 speed
Display Meter LCD
Front fork Front fork Suspension front fork
Front tire 27.5*2.1
Tire
Rear tire 27.5*2.1
Suitable height 155-200cm
Load capacity 265lbs(120kg)
Speed <25 km/h, based on terrain & rider weight
Riding
Range With PAS 80-100km
requirement
Suitable terrain Hard surface, flat road, ramp under 15°
Working temp. 0°C to 40°C
Storage temp. -20°C to 50°C
Vehicle weight Net weight 27kg
Input voltage 110V, 50/60HZ
Charger
Output voltage 42V, 2A
Charging time 6-8.5 hours
Parameters
inch
inch
-05 -

2.2 Main Parts

Electric Bike
Charger
8-10/13-15/14-17 Spanner
4/5/6 Allen Key
H
& +" Screwdriver
User Manual
Warranty Card
3. Meter Operation
3.1 Meter instruction
3.2 Meter operation
Meter operation
To switch on/off the To change assistance
e-bike system, hold level, press the UP /
the MODE bottom DOWN to increase
and decrease until
for 2s. The default
value is PAS "1".
the desired
assistance level is
displayed.
1
1
3
3
1
1
1
Full electric function:
Press "-", until the
PAS become "0"，it's
electric function.
