Setting Operating Mode - Flex FHE 2-22 SDS-plus Originalbetriebsanleitung

 Insert insertion tool (1.) and turn (2.)
it until it locks.
 Check lock by pulling on the insertion tool.
Removing the tools
WARNING!
Before performing any work on the electric
power tool, pull out the mains plug.
CAUTION!
Used insertion tools may become hot.
Wear protective gloves!
 Pull locking sleeve backwards (1.).
 Remove insertion tool (2.).

Setting operating mode

CAUTION!
Do not change operating mode until
the electric power tool is at a standstill.
 Press release button.
16
All manuals and user guides at all-guides.com
 Setting rotary knob to the required
The release button must visibly lock
(jump out) in the
(hammer drilling) positions.
Setting direction of rotation
Do not change operating mode until
the electric power tool is at a standstill.
 Set switch for selecting direction
Switching on the power tool
Without locking the switch:
 Press and hold down the switch.
Switch off the machine:
 Release the switch.
operating mode:
Drilling
Hammer drilling
NOTE!
(drilling) and
CAUTION!
of rotation to the required position:
– L counter-clockwise
– R Clockwise
The electric power tool switch enables
the speed or impact rate to be increased
slowly to the maximum value.
FHE 2-22
