MECHANICAL INSTALLATION

A
B
F
G
D
C
E
In particular, its main features are:
A. UPPER BRACKET (with hole)
B. UPPER BRACKET (with integrated pin)
C. LOW BRACKET (with hole)
D. LOW BRACKET (with integrated pin)
E. REAR BRACKET (with joint and quick-release pin)
F. RDNET NETWORK/AUDIO CONTROL SECTION
G. POWER SUPPLY UNIT SECTION
DVA MINI G2 Code 420120326 REV.1.0
