1. WLAN antenna: For wireless reception, please connect the WLAN antenna provided
here.
2. FM antenna: You can connect the provided telescopic antenna here. If you want to
connect a cable here instead, please use the provided antenna adapter.
3. POWER switch: Disconnects your iRadio from mains.
4. POWER: Connect the provided line cable to this jack.
5. LAN: For wired network operation, use this RJ45 jack.
6. USB: Use the USB port to connect memory devices like external hard discs or mem-
ory sticks. Your NOXON supports both USB 1.x and 2.0 devices.
7. LINE OUT: You can connect this 3.5 mm stereo jack to an amplifier or active speak-
ers. When this jack is occupied, the internal speakers are muted.
8. HEADPHONE: Here, you can connect your headphones if you want to have the
sound of the iRadio all to yourself. If the headphones are connected, the internal
speakers are muted.
