DB500H FEATURES
19 - REMOTE SOCKET – Allows you to connect an external remote footswitch (FS2-MINI)
for remote switching of TUBE DRIVE and MUTE.
20 - TUNER SOCKET - Plug your external tuning device in here. The signal is still sent to
the tuner socket even when the unit is in MUTE mode allowing silent tuning.
21 – COMBI Socket – Speakon NL2 compatible twist lock and 6.3mm jack. Provided to
connect your external cabinet. Please make sure the total cabinet impedance is no
less than 4 Ohms i.e. you can use a single 4 Ohm rated cabinet or 2 x 8 Ohm rated
cabinets may be used.
8
USER MANUAL EN
20
21
19
